Wolfe Ridge 28 Ton Super High Output Commercial Log Splitter

Wolfe Ridge 28 Ton Super High Output Commercial Log Splitter

SKU W28SHO
IN STORE ONLY
Check In-Store Availability

Add to Cart
Free Shipping Icon

Flexible Pickup & Delivery

Choose from shipping or buy online, pick up in-store options. Did we mention that you get free shipping on All Festool orders?

Learn More
Authorized Dealer Icon

Authorized Dealer

We are an authorized dealer of several top brands, providing high-quality products with unmatched service.

Learn More
HRM Heart - Family Owned Icon

Family-owned

We are a fourth-generation family-owned business built on community, trust, and family values.

Learn More
Hartville Hardware Logo - Price Pledge Icon

Price Pledge

We will price-match items our customers find at local competitors for less money on in-store and online purchases.

Learn More

Wolfe Ridge 28 Ton Super High Output Commercial Log Splitter is a versatile and powerful log splitter ideal for any job. This log splitter features an extra long 700 lb. capacity hydraulic log lift and sorting table to accommodate large logs. With a push block that exerts a force of 28 tons and has a 24-inch stroke, this model can split both small and large seasoned logs at an out-and-back cycle time of only 5.5 seconds.

This log splitter includes both a 4-way wedge and a 6-way wedge, to keep the size of the firewood consistent, regardless of the diameter of the log. Plus, it includes a prince auto-cycle valve for easy operation. Despite its large size, this log splitter is highway towable and includes a folding tongue to attach to a trailer for easy portability.

Note: Product images may show optional equipment not included in base price. See below for additional options.

Wolfe Ridge products are special-order items. Call or stop in-store to order.

The 28 Ton Supor High-Output Log Splitter is available in any of the following colors:
  • Red Baron Powder Coated Paint: $0.00
  • Stihl Orange Powder Coated Paint: $0.00
  • Gun Metal Gray Powder Coated Paint: $0.00
  • Dark Sapphire Powder Coated Paint: $0.00
  • Other Frame Colors: $100.00

The 28 Ton Supor High-Output Log Splitter may be special-ordered with any of the following options at an additional cost:
  • 25 HP Kubota diesel 38 GPM hydraulic pump: $6,000.00
  • Honda GX800 EFI 25 hp engine, 38 GPM double pump: $3,500.00
  • 12 Way Log Splitting Wedge: $800.00
  • Heavy duty welded on solid steel fenders: $250.00
  • 14″ radial tires on aluminum wheels: $200.00
  • LED tail light package: $200.00
  • 30″ stroke (includes sorting table extension): $600.00
  • 36″ stroke (includes sorting table extension): $1,000.00
  • Overhead LED flood lights (needs electric start): $300.00

Engine

Honda 20 V-Twin HP Gx630

Electric Start & Interstate Battery

Yes

Tonnage

28 Ton

Pressure

3000 PSI Max

Hydraulic Pump

28 GPM Cast Iron Pump

Hydraulic Valve

Prince Auto Cycle Valve

Cycle Time

5.5 Second

Beam

8 inches

Beam Height

32 inches

Splitting Wedge

12 inches AR400 Steel

Hydraulic Log Lift Capacity

700 pounds

Hydraulic Cylinder Bore

5 inches Magnum Bore

Hydraulic Cylinder Stroke

24 inches

Maximum Log Length

25 inches

Maximum Log Width

24 inches

Hydraulic Fluid Type

AW-32 / ISO 32

Hydraulic Oil Capacity

30 Gallons Total, 28 Gallons to Refill Tank

Hydraulic Reservoir

28 Gallon TIG Welded Aluminum

Hydraulic Oil Cooler

12 VDC Thermostatic Control

Hydraulic Oil Filter

Baldwin BT287-10

Hitch Coupler Dimensions

2 inches

Hitch

3 inches Folding Tongue Included

Maximum Towing Speed

80 MPH

Spark Arrester

Yes

Fuel Valve

Yes

Wedge

4-Way; 6-Way

Auto Cycle Hydraulic Valve

Yes

Overall Dimensions

148 inches x 69 inches x 45 inches

Paint Finish

Sand Blasted and Powder Coated Paint

Dry Weight

2,000 pounds

Tire Rims

6 inches x 14 inches

Tires

26 inches Radial

AXLes

Dexter with leaf springs

Engine Honda 20 V-Twin HP Gx630
Electric Start & Interstate Battery Yes
Tonnage 28 Ton
Pressure 3000 PSI Max
Hydraulic Pump 28 GPM Cast Iron Pump
Hydraulic Valve Prince Auto Cycle Valve
Cycle Time 5.5 Second
Beam 8 inches
Beam Height 32 inches
Splitting Wedge 12 inches AR400 Steel
Hydraulic Log Lift Capacity 700 pounds
Hydraulic Cylinder Bore 5 inches Magnum Bore
Hydraulic Cylinder Stroke 24 inches
Maximum Log Length 25 inches
Maximum Log Width 24 inches
Hydraulic Fluid Type AW-32 / ISO 32
Hydraulic Oil Capacity 30 Gallons Total, 28 Gallons to Refill Tank
Hydraulic Reservoir 28 Gallon TIG Welded Aluminum
Hydraulic Oil Cooler 12 VDC Thermostatic Control
Hydraulic Oil Filter Baldwin BT287-10
Hitch Coupler Dimensions 2 inches
Hitch 3 inches Folding Tongue Included
Maximum Towing Speed 80 MPH
Spark Arrester Yes
Fuel Valve Yes
Wedge 4-Way; 6-Way
Auto Cycle Hydraulic Valve Yes
Overall Dimensions 148 inches x 69 inches x 45 inches
Paint Finish Sand Blasted and Powder Coated Paint
Dry Weight 2,000 pounds
Tire Rims 6 inches x 14 inches
Tires 26 inches Radial
AXLes Dexter with leaf springs

Misplace the user manual? No problem! Hartville Hardware is here to help. Below is the user manual for the Wolfe Ridge 28SHO Log Splitter. Read it before you buy it, or come back and download it if you have any questions after getting your log splitter home.

Wolfe Ridge 28SHO Log Splitter User Guide
