Center Grate	Included
Cooktop Burner Grate Material	Heavy Cast Iron
Cooktop Surface	Deep Recessed, Gray
Burner - Left Rear	5,000 BTU Precise Simmer
Optional Accessories	WB48X21543 Roller Rack
Sabbath Mode	Yes
Cooktop Type	Standard Grates
App Filter - Cooktop Type	Standard Grates
App Filter - Cabinet Width	Cooking 30 in. (Standard)
LP Conversion Kit	Included
Burner - Right Rear	9,500 BTU
WiFi Connect	Built-In
Ignition System	Electronic
Cooktop Burner Grate Features	Edge-to-Edge Grates
Drawer Type	Storage
Burner - Right Front	15,000 BTU
Oven Door Features	Big View Oven Window
Hertz	60
Control Type	Glass Touch
Top Burner BTU Rating - Nat. Gas (000's BTU's)	(1) 21.0 (1) 15.0; (2) 9.5; (1)5.0
Burner - Left Front	21,000 BTU Tri-ring Burner
App Filter - Control Type	Electronic touchpad
Oven Cooking Modes	Convection Bake, Convection Roast, Frozen Pizza Multi Rack, Frozen Pizza Single Rack (No Preheat), Frozen Snacks Multi Rack, Frozen Snacks Single Rack (No Preheat), No Preheat Air Fry, Proof, Warming
Depth Without Handle	26.875 in
Grill	Included, JXGRILL1
Configuration	Range with Smooth Glide Storage Drawer
Installation	Flush Appearance, Free-standing cut-out
Overall Width	30 in
Handle Color	Black Stainless
Net Weight	224 lb
Top Burner BTU Rating - LP (000's BTU's)	(1) 18.0; (1) 15.0; (2) 9.5; (1) 5.0
Cabinet Opening	30 in
Cabinet Width	30 in
Cooking System	True European Convection
App Filter - Cleaning Type	Steam and Self-Clean
Trim Kit	JXFILLR1DD, Optional
Bake/Broiler BTU Rating - LP (000's BTU's)	16.0 Bake / 13.5 Broiler
Overall Depth	29.5 in
App Filter - Edge-to-Edge Cooktop	Yes
Total Capacity (cubic feet)	5.6 cu ft

Self-Clean Oven Door Lock	Automatic
Burner - Center	9,500 BTU Dual Oval
Oven Interior Dimensions (W x H x D) (in.)	24 x 19-1/2 x 20-5/8
Handle	Designer Style
Depth with Door Open	47.5 in
Air Fry Basket	Optional- JXAFTRAY1VSS
Cooktop Burner Type	Sealed
Connected Capabilities	Amazon Alexa, DiGiorno, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant
Height to Top of Rear Vent Trim	37.625 in
App Filter - Product Type	Ranges Slide-In Single Oven
Cooktop Burner Grate Color	Matte Black
Oven Cleaning Type	Self-Clean with Steam Clean Option
App Filter - WiFi Connect	Built-In
Approximate Shipping Weight	244 lb
Overall Height	36.5 in
App Filter - Fuel Type	Gas
Control Knobs	Black Stainless
App Filter - Tri-Ring Burner	Yes
Griddle	Reversible Integrated Grill/Griddle (Included)
Control Location	Front controls
Color Appearance	Fingerprint Resistant Black Stainless
Fuel Type	Natural Gas
Warranty Notes	See written warranty for full details
Interior Oven Light	1 Incandescent
App Filter - Convection	Yes
Dual Ring Burners	Yes
OU Certified	No
Cooking Technology	Convection
Volts/Hertz/Amps	120v; 60Hz; 15A
App Filter - Cooking Technology	Convection
Oven Rack Features	3 Self-Clean Oven Racks
App Filter - Drawer Type	Storage
Product Type	Slide-In Single Oven
Parts Warranty	Limited 1-year entire appliance
Oven Interior	1 Incandescent Light, Black
Height to Cooking Surface (in.)	36 1/4 +/- 1/4
Electrical Requirements	120V
Labor Warranty	Limited 1-year entire appliance
Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)	16.0 Bake / 16.5 Broiler
