Handle Design
Designer Style
Volts/Hertz/Amps
120v; 60Hz; 15A
Burner - Center
10,000 BTU Oval
Ignition System
Electronic
App Filter - Product Type
Ranges Free-Standing Double Oven
LP Conversion Kit
Included
Griddle Accessory
Integrated Griddle (Included)
App Filter - Cabinet Width
Cooking 30 in. (Standard)
Cooktop Burner Grate Material
Heavy Cast Iron
Cooktop Type
Continuous Grates with Griddle
Parts Warranty
Limited 1-year entire appliance
App Filter - Control Type
Electronic touchpad
Oven Cleaning Type
Steam Clean
Burner - Right Rear
12,000 BTU
Burner - Left Front
15,000 BTU
Burner - Left Rear
5,000 BTU Precise Simmer
Cooktop Surface
Edge-to-Edge, Gray, One-Piece Upswept, Porcelain-Enamel
Color Appearance
Stainless Steel
Cooktop Burner Grate Color
Matte Black
Burner - Right Front
9,500 BTU
Total Capacity (cubic feet)
6.8 cu ft
Approximate Shipping Weight
225 lb
Depth Without Handle
26.75 in
Handle Color
Stainless Steel
Control Knobs
Stainless Steel Appearance, Weighted
Oven Rack Features
3 Oven Racks
Oven Rack Positions (Single or Upper/Lower)
2 / 5
Interior Oven Light
1 Auto Incandescent (Both Ovens)
App Filter - Fuel Type
Gas
Warranty Notes
See written warranty for full details
Product Type
Free-Standing Double Oven
Griddle
Integrated (Included)
App Filter - Edge-to-Edge Cooktop
Yes
Bake/Broiler BTU Rating - LP (000's BTU's)
7.0 / 120V Bake Assist Element (Upper); 13.5 / 13.5 (Lower)
App Filter - Convection
Yes
Oven Control Features
Audible Preheat Signal, Control Lock Capability, Sabbath Mode
Oven Cooking Modes
Convection Bake, Convection Roast, No Preheat Air Fry
Cooking Technology
Traditional Upper; Convection Lower
App Filter - Cooking Technology
Convection, Traditional
Control Type
Electronic Touch
Configuration
Double Oven Range
Cooktop Burner Type
Sealed
Center Grate
Optional - JXGRATE1
Air Fry Basket
Optional- JXAFTRAY1VSS
Height to Cooking Surface (in.)
36 - 36 1/2
Electrical Requirements
120V
Oven Interior Dimensions (W x H x D) (in.)
24 x 9-1/2 x 19-1/8 - Upper; 24 x 15 x 20-5/8 - Lower
Top Burner BTU Rating - LP (000's BTU's)
(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 8.0
App Filter - Cooktop Type
Continuous Grates with Griddle
Capacity (Cu. Ft.)
2.5 Upper / 4.3 Lower
Oven Door Features
Big View Oven Window
Depth with Door Open
43.5 in
Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)
7.0 / 120V Bake Assist Element (Upper); 16.5 / 14.0 (Lower)
Cooktop Burner Grate Features
Dishwasher Safe
Top Burner BTU Rating - Nat. Gas (000's BTU's)
(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 10.0
Labor Warranty
Limited 1-year entire appliance
| Handle Design |
Designer Style |
| Volts/Hertz/Amps |
120v; 60Hz; 15A |
| Burner - Center |
10,000 BTU Oval |
| Ignition System |
Electronic |
| App Filter - Product Type |
Ranges Free-Standing Double Oven |
| LP Conversion Kit |
Included |
| Griddle Accessory |
Integrated Griddle (Included) |
| App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
| Cooktop Burner Grate Material |
Heavy Cast Iron |
| Sabbath Mode |
Yes |
| Cooktop Type |
Continuous Grates with Griddle |
| Parts Warranty |
Limited 1-year entire appliance |
| App Filter - Control Type |
Electronic touchpad |
| Oven Cleaning Type |
Steam Clean |
| Cabinet Width |
30 in |
| Burner - Right Rear |
12,000 BTU |
| Fuel Type |
Natural Gas |
| Control Location |
Front |
| Burner - Left Front |
15,000 BTU |
| Burner - Left Rear |
5,000 BTU Precise Simmer |
| Cooktop Surface |
Edge-to-Edge, Gray, One-Piece Upswept, Porcelain-Enamel |
| Color Appearance |
Stainless Steel |
| Cooktop Burner Grate Color |
Matte Black |
| Overall Width |
30 in |
| Burner - Right Front |
9,500 BTU |
| Total Capacity (cubic feet) |
6.8 cu ft |
| Approximate Shipping Weight |
225 lb |
| Depth Without Handle |
26.75 in |
| Handle Color |
Stainless Steel |
| Control Knobs |
Stainless Steel Appearance, Weighted |
| Oven Rack Features |
3 Oven Racks |
| Oven Rack Positions (Single or Upper/Lower) |
2 / 5 |
| Interior Oven Light |
1 Auto Incandescent (Both Ovens) |
| Overall Depth |
29.25 in |
| Hertz |
60 |
| Warranty Notes |
See written warranty for full details |
| Product Type |
Free-Standing Double Oven |
| Griddle |
Integrated (Included) |
| App Filter - Edge-to-Edge Cooktop |
Yes |
| Bake/Broiler BTU Rating - LP (000's BTU's) |
7.0 / 120V Bake Assist Element (Upper); 13.5 / 13.5 (Lower) |
| App Filter - Convection |
Yes |
| Oven Control Features |
Audible Preheat Signal, Control Lock Capability, Sabbath Mode |
| Oven Cooking Modes |
Convection Bake, Convection Roast, No Preheat Air Fry |
| Cooking Technology |
Traditional Upper; Convection Lower |
| OU Certified |
No |
| App Filter - Cooking Technology |
Convection, Traditional |
| Overall Height |
47.25 in |
| Control Type |
Electronic Touch |
| Configuration |
Double Oven Range |
| Cooktop Burner Type |
Sealed |
| Center Grate |
Optional - JXGRATE1 |
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| Height to Cooking Surface (in.) |
36 - 36 1/2 |
| Electrical Requirements |
120V |
| Net Weight |
205 lb |
| Oven Interior Dimensions (W x H x D) (in.) |
24 x 9-1/2 x 19-1/8 - Upper; 24 x 15 x 20-5/8 - Lower |
| Top Burner BTU Rating - LP (000's BTU's) |
(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 8.0 |
| App Filter - Cooktop Type |
Continuous Grates with Griddle |
| Capacity (Cu. Ft.) |
2.5 Upper / 4.3 Lower |
| Oven Door Features |
Big View Oven Window |
| Depth with Door Open |
43.5 in |
| Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) |
7.0 / 120V Bake Assist Element (Upper); 16.5 / 14.0 (Lower) |
| Cooktop Burner Grate Features |
Dishwasher Safe |
| Top Burner BTU Rating - Nat. Gas (000's BTU's) |
(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 10.0 |
| Labor Warranty |
Limited 1-year entire appliance |
