John Deere X580 Lawn Tractor with 54-in. Deck

Specifications

Engine:

• Power: 24 hp / 17.9 kW
• Oil change: No-tools oil drain with replaceable filter
• Manufacturer/model: FR730V
• Type: Overhead valve, full-pressure lube, oil filter
• Cylinders: V-twin, cast-iron liners
• Governor: Mechanical
• Choke/speed control: Separate levers, automatic choke return
• Cooling method: Air
• Air cleaner: Dry, replaceable

Fuel System:

• Type: Gasoline
• Fuel delivery: Pulse pump and carburetor
• Fuel gauge: Gauge on dash
• Fuel tank location: Rear
• Fuel fill opening: On left fender, 3 in. / 7.6 cm
• Fuel tank capacity: 4.4 U.S. gal. / 16.7 L

Electrical System:

• Battery: 12 V / 340 CCA
• Charging system: Flywheel alternator, regulated, 12 amp
• Engine starter: Bendix
• Hour meter: Yes
• Headlights: Two standard, incandescent, 27 W
• Taillights or reflector: Reflectors
• Backup lights: No
• Rear work lights: No
• 12-V outlet: Yes

Transaxle:

• Type: K72 hydrostatic integrated with transaxle
• Control: Twin Touch™ pedals
• Cruise control: Yes, button on dash
• Oil cooler: Fins and fan on transaxle
• Oil filter: Yes, replaceable
• Differential lock: Standard
• Forward speed: 0-7.2 mph / 0-11.6 km/h
• Reverse speed: 0-5.2 mph / 0-8.4 km/h
• Brakes: Internal wet disc

Chassis:

• Frame: Welded heavy-duty
• Primer/paint: E-coat/powder
• Weight bracket: Standard front and rear - each holds up to four Quik-Tatch weights, 42 lb / 19 kg
• Receiver hitch: No
• Front axle: Cast iron front axle, front wheel ball bearings
• Spindle bushings: Metal, replaceable
• Front tires: 16x6.5-8 turf
• Rear tires: 24x12-12 HDAP
• Hood material: Fully enclosed, molded-in color material reduces sound, will not rust or dent
• Fender deck material: Stamped steel
• Floor mats: Sure-grip rubber
• Storage: Yes, covered toolbox
• Service interval decal: Yes
• Fender handles/grips: Handles
• Cup holder: Yes
• Equipment mounting: Yes, heavy duty
• Maximum towing capacity: 800 lb / 363 kg

Steering:

• Type: Power, hydraulic
• Four-wheel steer: Not available on this model
• Steering wheel: 14 in. / 35.6 cm
• Tilt steering wheel: No
• Turning radius: 22 in. / 55.9 cm
• Uncut circle radius: 24 in. / 61 cm

Seat:

• Type: Cut-and-sewn high-back
• Seat back height: 21 in. / 53 cm
• Armrests: Optional
• Fore-aft adjustment: While seated, ball bearing slide rail, 15-position, 6.6 in. / 17 cm
• Seat suspension: Six-position parallel arm

Lift System:

• Type: Hydraulic
• Hydraulic outlets: No
• Mower cut height: 13 positions, 1-4 in. / 2.5-10.2 cm
• Cut height increments: 0.25 in. / 0.64 cm
• Preset cut height: Yes

Mower Deck:

• Type: Side discharge
• Cutting width: Accel Deep™ mower deck, 54 in. / 137 cm
• Construction: Forged steel deck shell
• Mower deck material: 10 gauge / 0.135 in. / 3.4 mm
• Mower wash port: Yes
• Mower drive system: Electric power take-off (PTO) clutch, in-line belt
• Mower wheels: Four
• Mower wheel adjustment: Seven-position, spring-loaded pin
• Mower level adjustment: Exact Adjust ports and deck-leveling gauge

Mower Attachability:

• Type: Roll under tractor
• Front draft arms: Attached with spring pins at two points
• Rear draft arms: Quick-pull pins
• Mower wheels rotate: Yes, 90 degrees for easy mower removal
• Drive system: Dual belts

Safety:

• Meets ANSI standard: Yes
• Meets OPEI standard: Yes
• Backup protection: Reverse Implement Option (RIO)
• Safety video: Yes

Buyer's Notes:

• Heavy-duty garden tractor transaxle
• Convenient power steering and hydraulic lift
• Built-in front and rear weight bracket

Warranty:

• 4 year/500 hour bumper-to-bumper (**Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.)

Optional Equipment:

• Mowers: 54XA (standard)
• Rear bagger: 7, 14, 19 bu / 247, 493, 670 L
• Powered material collection: Power Flow™ blower
• Mulching system: Yes, MulchControl™
• Front thatcher: 38, 46, 54 in. / 96.5, 116.8, 137.2 cm
• Front blade: 48 in. / 121.9 cm
• Snow blower: Two-stage, 47 in. / 119.4 cm
• Rotary tiller: Mechanical, 30 in. / 76.2 cm
• Sleeve hitch: Yes, implements include box scraper, rear blade, plow, disk, and cultivator
• Plow, moldboard: Yes
• Box scraper: Yes
• Cultivator: Yes
• Rear blade: Yes
• Sprayer: Tow-behind, 15, 25, 45 U.S. gal. / 56.8, 94.6, 170.3 L; Mounted, 25 U.S. gal. / 94.6 L
• Spreader: 125, 175 lb / 57.7, 79.4 kg; Mounted, 125 lb / 57.7 kg
• Front bumper: Standard front bumper/weight bracket
• Brush guard: Yes
• Weather protection: Weather enclosure
• Sun canopy: Yes
• Bucket holder: Yes, double bucket
• Grass striping: Lawn striping kit
• Tractor shovel: 40 in. / 101.6 cm
• Tow-behind tools: 19

Dimensions:

• Height: 52.7 in. / 1338 mm
• Overall length: 77.4 in. / 1966 mm
• Wheelbase: 51.2 in. / 1300 mm
• Width with mower: 68.4 in. / 1737 mm
• Width with mower (deflector raised for storage): 58.3 in. / 1481 mm
• Width without mower: 40.7 in. / 1034 mm
• Weight: Mower, no fuel: 777 lb / 352 kg
