John Deere 1023E Sub-Compact Utility Tractor

Only 2 left at Hartville

John Deere 1023E Sub-Compact Utility Tractor

SKU JD1023E

Add to Cart
Free Shipping Icon

Flexible Pickup & Delivery

Choose from shipping or buy online, pick up in-store options. Did we mention that you get free shipping on All Festool orders?

Learn More
Authorized Dealer Icon

Authorized Dealer

We are an authorized dealer of several top brands, providing high-quality products with unmatched service.

Learn More
HRM Heart - Family Owned Icon

Family-owned

We are a fourth-generation family-owned business built on community, trust, and family values.

Learn More
Hartville Hardware Logo - Price Pledge Icon

Price Pledge

We will price-match items our customers find at local competitors for less money on in-store and online purchases.

Learn More

John Deere 1023E Sub-Compact Utility Tractor is designed to make your tasks easier and more efficient.

Features:

  • Featuring a powerful Final Tier 4-compliant diesel engine, this tractor provides the performance and reliability you expect from John Deere.
  • The AutoConnect™ mid-mower deck can be installed or removed in less than 5 minutes, allowing you to spend more time working and less time switching equipment.
  • The Twin Touch foot controls and Hydrostatic transmission (HST) ensure smooth and easy operation, while the standard four-wheel drive (4WD) and power steering offer excellent maneuverability.
  • The open operator’s station is designed for comfort and convenience, with multiple mid-mower lift system options available for added flexibility.

View Brochure
View Implements and Attachments


Model Number: 025NLV


Model may be pictured with optional features. Additional options may be available to add for an additional price.

Looking for John Deere equipment? We are a certified John Deere dealer with all the equipment, accessories, and parts you need to maintain your perfect lawn. Does your mower or tractor need serviced or repaired? Schedule a service appointment, and one of our trained experts will get it running like new. Near downtown Hartville, our location is perfect for Stark, Summit, and Portage County residents in Hartville, Uniontown, Alliance, Mogadore, Jackson Township, and the Canton area, including North Canton.

Engine:

Power

21.5 hp / 16 kW

Rated engine speed

3200 rpm

Manufacturer/model

Yanmar® 3TNM74F-NCJT

Type

Diesel

Emissions compliance

Final Tier 4

Displacement

60.6 cu inches / 0.993 L

Cylinders

Three

Bore and stroke

2.91 x 3.03 inches / 74 x 77 mm

Compression ratio

23.5:1

Lubrication

Pressurized

Cooling system

Water pump

Air cleaner

Dual element

Torque

35.2 pounds-ft / 47.7 Nm at 3200 rpm

Fuel System:

Type

Indirect injection

Fuel tank capacity

6.3 U.S. gallons / 24 L

Transmission:

Type

Hyardsrostatic - two range

Final drive

Spur gear

Brakes

Wet disc (left-hand pedal)

Steering

Power

AXLe capacity

Front - 1349 pounds / 612 kg; Rear - 1576 pounds / 715 kg

Differential lock

Yes

Hydraulics:

Type

Open center

Pump rated output

6.3 gpm / 24 L/min (combined)

Pump type

Single gear

Maximum operating pressure

2000 psi / 138 bar

Draft control sensing

Select control

Remote control valves available

Three

3-Point Hitch:

Type

Limited Category 1

Lift capacity, 24 inches behind link arms

758 pounds / 344 kg

Power Take-Off (PTO):

Rear PTO

540 rpm

Mid PTO

2100 rpm

Control

Independent

Clutch

Wet disk

Brake

Wet disk

Fluid Capacities:

Crankcase with filter

2.7 L / 2.9 qt

Transmission and Hydraulic system

12.3 L / 3.2 gal

Dimensions:

Wheepoundsase

57.1 inches / 1450 mm

Front aXLe clearance

7.7 inches / 195 mm

Turning radius without brakes

8.2 ft / 2.51 m

Shipping weight (open station)

1446 pounds / 656 kg

Tires:

Front

R3 Turf - 18x8.50-10; R4 - 18x8.5-10

Rear

R3 Turf - 26x12-12; R4 - 26x12-12

Front tread range

36.7 inches / 931 mm

Rear tread spacing

35.2 inches / 895 mm

Miscellaneous:

Toopoundsox

Yes

Engine:
Power 21.5 hp / 16 kW
Rated engine speed 3200 rpm
Manufacturer/model Yanmar® 3TNM74F-NCJT
Type Diesel
Emissions compliance Final Tier 4
Displacement 60.6 cu inches / 0.993 L
Cylinders Three
Bore and stroke 2.91 x 3.03 inches / 74 x 77 mm
Compression ratio 23.5:1
Lubrication Pressurized
Cooling system Water pump
Air cleaner Dual element
Torque 35.2 pounds-ft / 47.7 Nm at 3200 rpm
Fuel System:
Type Indirect injection
Fuel tank capacity 6.3 U.S. gallons / 24 L
Transmission:
Type Hyardsrostatic - two range
Final drive Spur gear
Brakes Wet disc (left-hand pedal)
Steering Power
AXLe capacity Front - 1349 pounds / 612 kg; Rear - 1576 pounds / 715 kg
Differential lock Yes
Hydraulics:
Type Open center
Pump rated output 6.3 gpm / 24 L/min (combined)
Pump type Single gear
Maximum operating pressure 2000 psi / 138 bar
Draft control sensing Select control
Remote control valves available Three
3-Point Hitch:
Type Limited Category 1
Lift capacity, 24 inches behind link arms 758 pounds / 344 kg
Power Take-Off (PTO):
Rear PTO 540 rpm
Mid PTO 2100 rpm
Control Independent
Clutch Wet disk
Brake Wet disk
Fluid Capacities:
Crankcase with filter 2.7 L / 2.9 qt
Transmission and Hydraulic system 12.3 L / 3.2 gal
Dimensions:
Wheepoundsase 57.1 inches / 1450 mm
Front aXLe clearance 7.7 inches / 195 mm
Turning radius without brakes 8.2 ft / 2.51 m
Shipping weight (open station) 1446 pounds / 656 kg
Tires:
Front R3 Turf - 18x8.50-10; R4 - 18x8.5-10
Rear R3 Turf - 26x12-12; R4 - 26x12-12
Front tread range 36.7 inches / 931 mm
Rear tread spacing 35.2 inches / 895 mm
Miscellaneous:
Toopoundsox Yes

John Deere offers a warranty for all Turf and Utility Equipment that they manufacture.

Each piece of equipment carries a specific warranty including a specific warranty period. Please contact your Hartville Hardware Outdoor Power Sales Team Member for more details.
