Cooktop Surface
Gray Patterned Ceramic Glass, One-Piece Upswept
Color Appearance
Stainless Steel/Gray
Electrical Requirements
208/240V ; 60Hz ; 40A
App Filter - Cooking Technology
Convection, Traditional
App Filter - Cleaning Type
Steam and Manual
Warranty Notes
See written warranty for full details
Textured Steel Side Panels
Yes
App Filter - Product Type
Ranges Free-Standing Double Oven
App Filter - Cooktop Type
Radiant Smoothtop
Cooking Technology
Traditional Upper; Convection Lower
Labor Warranty
Limited 1-year entire appliance
Total Capacity (cubic feet)
6.6 cu ft
Capacity (Cu. Ft.)
2.2 Upper / 4.4 Lower
Oven Interior Dimensions (lower)
24 x 17 1/2 x 18 1/4
App Filter - Convection
Yes
Element - Left Front
9"/6" 3100W Power Boil
Control Type
Digital Temperature Display, Electronic, Touchpads
Element - Right Rear
6" 1200W
Height to Cooking Surface (in.)
35 3/4 - 36 1/2
Control Location
Backsplash
Oven Features
6-Pass Bake Element (Lower), 6-Pass Broil Element (Both Ovens), 8-Pass Bake Element (Upper)
Cooktop Type
Radiant Smoothtop
Oven Door Features
2-Piece Stainless/Glass, Big View Oven Window
Oven Interior Dimensions (upper)
24 x 8-7/8 x 18-1/4
App Filter - Cabinet Width
Cooking 30 in. (Standard)
Depth with Door Open
45 in
Element - Left Rear
6" 1200W
Depth Without Handle
25.75 in
Product Type
Free-Standing Double Oven
Interior Oven Light
2 Incandescent (1 Upper and 1 Lower), Preheat Notification (Both Ovens)
Parts Warranty
Limited 1-year entire appliance
Control Knobs
Stainless Steel Appearance
Element - Right Front
12"/9" 3000W
Cooktop Burner Type
Radiant, Smoothtop
App Filter - Fuel Type
Electric
Approximate Shipping Weight
226 lb
Broiler Wattage
2500W Upper / 3600W Lower
Oven Control Features
Audible Preheat Signal, Auto Oven Shut-Off with Override, Control Lock Capability, Convection Bake, Convection Roast, C° or F° Programmable, Delay Bake Option (Time Cook), Delay Clean Option, Electronic Clock & Kitchen Timer, Hi / Low Broil, Oven "ON" Light, Sabbath Mode
Air Fry Basket
Optional- JXAFTRAY1VSS
Oven Rack Positions (Single or Upper/Lower)
2 / 7
Oven Cleaning Type
Steam Clean (Both Ovens)
Bake Wattage
2500W Upper / 2650 Lower
Heating Element "ON" Indicator Light
1
Handle Design
Designer Style
Configuration
Double Oven Range
Handle Color
Stainless Steel
Oven Cooking Modes
No Preheat Air Fry, Warming
App Filter - Control Type
Electronic touchpad
Oven Rack Features
3 Heavy-Duty Oven Racks
Element - Center
6" 80W Warming Zone
Hot Surface Indicator Lights
1
| Cooktop Surface |
Gray Patterned Ceramic Glass, One-Piece Upswept |
| Color Appearance |
Stainless Steel/Gray |
| Electrical Requirements |
208/240V ; 60Hz ; 40A |
| Overall Height |
47.5 in |
| App Filter - Cooking Technology |
Convection, Traditional |
| App Filter - Cleaning Type |
Steam and Manual |
| Melt Setting |
Yes |
| Warranty Notes |
See written warranty for full details |
| Power Boil Burner |
Yes |
| OU Certified |
No |
| Textured Steel Side Panels |
Yes |
| App Filter - Product Type |
Ranges Free-Standing Double Oven |
| Amp Rating at 240V |
40 |
| App Filter - Cooktop Type |
Radiant Smoothtop |
| Cooking Technology |
Traditional Upper; Convection Lower |
| Labor Warranty |
Limited 1-year entire appliance |
| Total Capacity (cubic feet) |
6.6 cu ft |
| Capacity (Cu. Ft.) |
2.2 Upper / 4.4 Lower |
| Oven Interior Dimensions (lower) |
24 x 17 1/2 x 18 1/4 |
| App Filter - Convection |
Yes |
| Element - Left Front |
9"/6" 3100W Power Boil |
| Control Type |
Digital Temperature Display, Electronic, Touchpads |
| Element - Right Rear |
6" 1200W |
| Height to Cooking Surface (in.) |
35 3/4 - 36 1/2 |
| Control Location |
Backsplash |
| KW Rating at 240V |
15.6 |
| Oven Features |
6-Pass Bake Element (Lower), 6-Pass Broil Element (Both Ovens), 8-Pass Bake Element (Upper) |
| Sabbath Mode |
Yes |
| Cooktop Type |
Radiant Smoothtop |
| Cabinet Width |
30 in |
| Oven Door Features |
2-Piece Stainless/Glass, Big View Oven Window |
| Overall Depth |
28.25 in |
| Oven Interior Dimensions (upper) |
24 x 8-7/8 x 18-1/4 |
| App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
| Depth with Door Open |
45 in |
| KW Rating at 208V |
11.7 |
| Element - Left Rear |
6" 1200W |
| Fuel Type |
Electric |
| Depth Without Handle |
25.75 in |
| Product Type |
Free-Standing Double Oven |
| Interior Oven Light |
2 Incandescent (1 Upper and 1 Lower), Preheat Notification (Both Ovens) |
| Parts Warranty |
Limited 1-year entire appliance |
| Control Knobs |
Stainless Steel Appearance |
| Element - Right Front |
12"/9" 3000W |
| Cooktop Burner Type |
Radiant, Smoothtop |
| Overall Width |
29.875 in |
| App Filter - Fuel Type |
Electric |
| Approximate Shipping Weight |
226 lb |
| Broiler Wattage |
2500W Upper / 3600W Lower |
| Oven Control Features |
Audible Preheat Signal, Auto Oven Shut-Off with Override, Control Lock Capability, Convection Bake, Convection Roast, C° or F° Programmable, Delay Bake Option (Time Cook), Delay Clean Option, Electronic Clock & Kitchen Timer, Hi / Low Broil, Oven "ON" Light, Sabbath Mode |
| Amp Rating at 208V |
40 |
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| Oven Rack Positions (Single or Upper/Lower) |
2 / 7 |
| Oven Cleaning Type |
Steam Clean (Both Ovens) |
| Bake Wattage |
2500W Upper / 2650 Lower |
| Heating Element "ON" Indicator Light |
1 |
| Handle Design |
Designer Style |
| Net Weight |
204 lb |
| Configuration |
Double Oven Range |
| Handle Color |
Stainless Steel |
| Oven Cooking Modes |
No Preheat Air Fry, Warming |
| App Filter - Control Type |
Electronic touchpad |
| Oven Rack Features |
3 Heavy-Duty Oven Racks |
| Element - Center |
6" 80W Warming Zone |
| Hot Surface Indicator Lights |
1 |
