Warranty Notes	See written warranty for full details
KW Rating at 240V	11.7
Fuel Type	Electric
Control Type	Digital Temperature Display, Electronic, Touchpads
OU Certified	No
Cooking Technology	Traditional
Handle Color	Black
Overall Height	47 in
Element - Right Front	8" 2400W Temp Limiting Coil
App Filter - Cooktop Type	Coil
App Filter - Convection	No
Element - Right Rear	6" 1250W Temp Limiting Coil
Cooktop Type	Coil
Drawer Type	Storage
Lift-Up Cooktop With Support Rods	Yes
Electrical Requirements	208/240V ; 60Hz ; 40A
Bake Wattage	2585W
App Filter - Drawer Type	Storage
Cooktop Burner Type	Coil
Oven Door Features	Big View Oven Window, Glass Door
Oven Cleaning Type	Self-Clean
Cooktop Surface	One-Piece Upswept, Porcelain-Enamel
Parts Warranty	Limited 1-year entire appliance
Hertz	60
App Filter - Fuel Type	Electric
Cabinet Width	30 in
Heating Element "ON" Indicator Light	Yes
App Filter - Cleaning Type	Self-Clean
Removable One-Piece Drip Bowls	Black Porcelain Enameled
Storage Drawer Features	Removable Full-Width
App Filter - Cooking Technology	Traditional
Textured Steel Side Panels	Yes

Color Appearance	Black
Height to Cooking Surface (in.)	36 - 36 1/2
Broiler Wattage	3410W
Amp Rating at 208V	40
Total Capacity (cubic feet)	5 cu ft
Oven Interior	1 Incandescent Light
App Filter - Voltage	240V
App Filter - Cabinet Width	Cooking 30 in. (Standard)
Depth with Door Open	46.25 in
App Filter - Product Type	Ranges Free-Standing Single Oven
Control Knobs	Stainless Steel Appearance
Oven Interior Dimensions (W x H x D) (in.)	23-3/4 x 19 x 18-1/2
Depth Without Handle	26.25 in
Oven Rack Features	2 Oven Racks
Overall Depth	28.75 in
Oven Control Features	Audible Preheat Signal, Auto Oven Shut-Off with Override, Auto Self Clean, Control Lock Capability, Delay Bake Option (Time Bake), Delay Clean Option, Electronic Clock & Kitchen Timer, Hi / Low Broil, Oven "ON" Light, Self-Clean Cool Down Time Display, Self-Cleaning Cycling Light
Labor Warranty	Limited 1-year entire appliance
Approximate Shipping Weight	170 lb
KW Rating at 208V	8.8
Element - Left Rear	8" 2400W Temp Limiting Coil
Control Location	Backsplash
Net Weight	150 lb
App Filter - Control Type	Electronic touchpad
Overall Width	30 in
Amp Rating at 240V	40
Element - Left Front	6" 1250W Temp Limiting Coil
Oven Features	4-Pass Bake Element, 4-Pass Broil Element
Oven Rack Positions (Single or Upper/Lower)	6
Product Type	Free-Standing Single Oven
Configuration	Range with Storage Drawer
Handle	Designer Style
