App Filter - Control Type
Electronic touchpad
Cutout Height (in)
27.3125 in
Color Appearance
Matte Black
Cooking Technology
Convection
Oven Features
10-Pass Bake Element, 10-Pass Dual Broil Element, Closed Door Broiling
Electrical Requirements
208/240V ; 60Hz ; 20A
Cutout Width (in)
28.625 in
Oven Door Features
Big View Oven Window, Soft-Close Hinges
Air Fry Basket
Optional- JXAFTRAY1VSS
Handle
Café Pro Style, Customizable
Warranty Notes
See written warranty for full details
Oven Interior Dimensions (W x H x D) (in.)
25 x 17-3/8 x 20 1/4
Self-Clean Oven Door Lock
Automatic
App Filter - Cabinet Width
Cooking 30 in. (Standard)
App Filter - Product Type
Wall Oven Single
Connected Capabilities
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant
Total Capacity (cubic feet)
5 cu ft
App Filter - WiFi Connect
Built-In
Oven Rack Features
2 Self-Clean Roller Racks, Embossed Rack Positions
Control Type
7" Full-Color Touch LCD Screen
App Filter - Cleaning Type
Steam and Self-Clean
Handle Color
Brushed Stainless
Approximate Shipping Weight
177 lb
Handle Design
Café Stainless
App Filter - Fuel Type
Electric
App Filter - Convection
Yes
App Filter - Cooking Technology
Convection
Optional Kits
CXWS0H0PMBT Brushed Black, CXWS0H0PMBZ Brushed Bronze, CXWS0H0PMCG Brushed Brass, CXWS0H0PMCU Brushed Copper, CXWS0H0PMFB Flat Black, CXWS0H0PMSS Brushed Stainless
Oven Rack Positions (Single or Upper/Lower)
6
Oven Interior
2 Halogen Interior Oven Lights, Black Gloss Finish, Hidden Bake
Cleaning Time
Variable with Delay Clean Option
Cutout Dimensions (w x h x d) (in.)
28-5/8 x 27-5/16 x 23-1/2
Oven Control Features
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Dehydration, Delay Time, Electronic Clock & Kitchen Timer, Mis-Wire Detection, Oven Camera, Proof Mode, Remote Enabled, Sabbath Mode, Scan-to-cook, Temperature Probe, Warm Mode
Labor Warranty
Limited 1-year entire appliance
Oven Cleaning Type
Self-Clean with Steam Clean Option
Optional Accessories
UXWORXR30 - 30" Never Scrub Roller Rack
Oven Cooking Modes
Convection Bake, Convection Bake Multi-Rack, Convection Broil Hi/Lo, Convection Roast, No Preheat Air Fry, Precision Cooking Modes, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode
Configuration
Single Oven
Installation
Above Warming Drawer, Side-by-Side, Under Built-In Advantium, Under Built-In Microwave, Under Cooktop, Undercounter
Cooking System
True European Convection with Direct Air
Parts Warranty
Limited 1-year entire appliance
Depth with Door Open
48.75 in
| App Filter - Control Type |
Electronic touchpad |
| Cutout Height (in) |
27.3125 in |
| Color Appearance |
Matte Black |
| Cooking Technology |
Convection |
| Oven Features |
10-Pass Bake Element, 10-Pass Dual Broil Element, Closed Door Broiling |
| Hertz |
60 |
| Electrical Requirements |
208/240V ; 60Hz ; 20A |
| Cutout Width (in) |
28.625 in |
| Oven Door Features |
Big View Oven Window, Soft-Close Hinges |
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| Handle |
Café Pro Style, Customizable |
| Warranty Notes |
See written warranty for full details |
| Oven Interior Dimensions (W x H x D) (in.) |
25 x 17-3/8 x 20 1/4 |
| Self-Clean Oven Door Lock |
Automatic |
| OU Certified |
No |
| Amp Rating at 240V |
20 |
| App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
| Cabinet Width |
30 in |
| Convection Wattage |
2400W |
| Overall Depth |
26.75 in |
| App Filter - Product Type |
Wall Oven Single |
| Broiler Wattage |
4300W |
| Fuel Type |
Electric |
| Connected Capabilities |
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant |
| Total Capacity (cubic feet) |
5 cu ft |
| App Filter - WiFi Connect |
Built-In |
| Oven Rack Features |
2 Self-Clean Roller Racks, Embossed Rack Positions |
| Control Type |
7" Full-Color Touch LCD Screen |
| App Filter - Cleaning Type |
Steam and Self-Clean |
| Handle Color |
Brushed Stainless |
| Approximate Shipping Weight |
177 lb |
| Handle Design |
Café Stainless |
| App Filter - Fuel Type |
Electric |
| App Filter - Convection |
Yes |
| App Filter - Cooking Technology |
Convection |
| Bake Wattage |
2850W |
| Optional Kits |
CXWS0H0PMBT Brushed Black, CXWS0H0PMBZ Brushed Bronze, CXWS0H0PMCG Brushed Brass, CXWS0H0PMCU Brushed Copper, CXWS0H0PMFB Flat Black, CXWS0H0PMSS Brushed Stainless |
| Oven Rack Positions (Single or Upper/Lower) |
6 |
| Oven Interior |
2 Halogen Interior Oven Lights, Black Gloss Finish, Hidden Bake |
| Cleaning Time |
Variable with Delay Clean Option |
| Cutout Dimensions (w x h x d) (in.) |
28-5/8 x 27-5/16 x 23-1/2 |
| Oven Control Features |
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Dehydration, Delay Time, Electronic Clock & Kitchen Timer, Mis-Wire Detection, Oven Camera, Proof Mode, Remote Enabled, Sabbath Mode, Scan-to-cook, Temperature Probe, Warm Mode |
| Labor Warranty |
Limited 1-year entire appliance |
| Oven Cleaning Type |
Self-Clean with Steam Clean Option |
| Optional Accessories |
UXWORXR30 - 30" Never Scrub Roller Rack |
| Product Type |
Single Oven |
| Amp Rating at 208V |
20 |
| Net Weight |
161 lb |
| Oven Cooking Modes |
Convection Bake, Convection Bake Multi-Rack, Convection Broil Hi/Lo, Convection Roast, No Preheat Air Fry, Precision Cooking Modes, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode |
| KW Rating at 240V |
4.2 |
| Configuration |
Single Oven |
| Installation |
Above Warming Drawer, Side-by-Side, Under Built-In Advantium, Under Built-In Microwave, Under Cooktop, Undercounter |
| Cooking System |
True European Convection with Direct Air |
| Parts Warranty |
Limited 1-year entire appliance |
| Overall Height |
28.625 in |
| WiFi Connect |
Built-In |
| Overall Width |
29.75 in |
| Cutout Depth (in) |
23.5 |
| Depth with Door Open |
48.75 in |
| Sabbath Mode |
Yes |
| KW Rating at 208V |
3.2 |
