Total Capacity (cubic feet)
10 cu ft
App Filter - WiFi Connect
Built-In
App Filter - Product Type
Wall Oven Double
Oven Rack Features
2 Roller Racks (Upper) 1 Roller Rack and 1 Flat Rack (Lower)
Cleaning Time
Variable with Delay Clean Option
Oven Cleaning Type
Self-Clean with Steam Clean Option
Cooking Technology
Convection
Connected Capabilities
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant
App Filter - Cooking Technology
Convection
Capacity (Cu. Ft.)
5.0 Upper / 5.0 Lower
Optional Accessories
UXWORXR30 - 30" Never Scrub Roller Rack
Cutout Height (in)
51.8125 in
Oven Features
10-Pass Bake Element, 10-Pass Dual Broil Element, Closed Door Broiling
Labor Warranty
Limited 1-year entire appliance
Control Type
7" Full-Color Touch LCD Screen
Oven Interior Dimensions (lower)
25 x 17-3/8 x 20-1/4
Oven Interior
2 Halogen Interior Oven Lights (Both Ovens), Black Gloss Finish, Hidden Bake
Handle Color
Brushed Stainless
Self-Clean Oven Door Lock
Automatic
Cutout Width (in)
28.5 in
App Filter - Control Type
Electronic touchpad
Oven Door Features
Drop-Down (Lower), Dual Window, French-Door (Upper)
Parts Warranty
Limited 1-year entire appliance
Cooking System
True European Convection with Direct Air (Both Ovens)
Oven Interior Dimensions (upper)
25 x 17-3/8 x 20-1/4
Color Appearance
Stainless Steel
Depth with Door Open
48.75 in
Approximate Shipping Weight
398 lb
Installation
Above Warming Drawer, Side-by-Side
Handle
Café Pro Style, Customizable
App Filter - Cabinet Width
Cooking 30 in. (Standard)
Air Fry Basket
Optional- JXAFTRAY1VSS
Oven Control Features
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Delay Time, Electronic Clock & Kitchen Timer, Mis-Wire Detection, Remote Enabled, Sabbath Mode, Scan-to-cook, Temperature Probe
Warranty Notes
See written warranty for full details
Oven Cooking Modes
Convection Bake, Convection Bake Multi-Rack, Convection Broil Hi/Lo, Convection Roast, No-Preheat Air Frying, Precision Cooking Modes, Proof, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode, Warming
App Filter - Cleaning Type
Steam and Self-Clean
Electrical Requirements
208/240V ; 60Hz ; 40A
Optional Kits
CXWDFHKPMBT Brushed Black, CXWDFHKPMBZ Brushed Bronze, CXWDFHKPMCG Brushed Brass, CXWDFHKPMCU Brushed Copper, CXWDFHKPMFB Flat Black, CXWDFHKPMSS Brushed Stainless
App Filter - Fuel Type
Electric
App Filter - Convection
Yes
Configuration
French Door
Cutout Dimensions (w x h x d) (in.)
28-1/2 x 51-13/16 x 23-1/2 (with pedestal rails); 28-1/2 x 50-1/4 x 23-1/2 (without pedestal rails)
| Fuel Type |
Electric |
| Amp Rating at 240V |
40 |
| Total Capacity (cubic feet) |
10 cu ft |
| App Filter - WiFi Connect |
Built-In |
| App Filter - Product Type |
Wall Oven Double |
| Oven Rack Features |
2 Roller Racks (Upper) 1 Roller Rack and 1 Flat Rack (Lower) |
| Cleaning Time |
Variable with Delay Clean Option |
| Oven Cleaning Type |
Self-Clean with Steam Clean Option |
| Cooking Technology |
Convection |
| Connected Capabilities |
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant |
| App Filter - Cooking Technology |
Convection |
| Sabbath Mode |
Yes |
| Capacity (Cu. Ft.) |
5.0 Upper / 5.0 Lower |
| Optional Accessories |
UXWORXR30 - 30" Never Scrub Roller Rack |
| Cutout Height (in) |
51.8125 in |
| Oven Features |
10-Pass Bake Element, 10-Pass Dual Broil Element, Closed Door Broiling |
| Amp Rating at 208V |
40 |
| Labor Warranty |
Limited 1-year entire appliance |
| Overall Width |
29.75 in |
| Overall Height |
53 in |
| Control Type |
7" Full-Color Touch LCD Screen |
| Oven Interior Dimensions (lower) |
25 x 17-3/8 x 20-1/4 |
| Product Type |
Double Oven |
| WiFi Connect |
Built-In |
| Broiler Wattage |
4300W |
| Oven Interior |
2 Halogen Interior Oven Lights (Both Ovens), Black Gloss Finish, Hidden Bake |
| Handle Color |
Brushed Stainless |
| KW Rating at 208V |
6.8 |
| Self-Clean Oven Door Lock |
Automatic |
| Cutout Width (in) |
28.5 in |
| Cabinet Width |
30 in |
| Bake Wattage |
2850W |
| App Filter - Control Type |
Electronic touchpad |
| Oven Door Features |
Drop-Down (Lower), Dual Window, French-Door (Upper) |
| Net Weight |
370 lb |
| Parts Warranty |
Limited 1-year entire appliance |
| Cooking System |
True European Convection with Direct Air (Both Ovens) |
| Oven Interior Dimensions (upper) |
25 x 17-3/8 x 20-1/4 |
| Color Appearance |
Stainless Steel |
| Depth with Door Open |
48.75 in |
| Convection Wattage |
2400W |
| Approximate Shipping Weight |
398 lb |
| Installation |
Above Warming Drawer, Side-by-Side |
| Handle |
Café Pro Style, Customizable |
| Hertz |
60 |
| App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| Oven Control Features |
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Delay Time, Electronic Clock & Kitchen Timer, Mis-Wire Detection, Remote Enabled, Sabbath Mode, Scan-to-cook, Temperature Probe |
| Warranty Notes |
See written warranty for full details |
| Oven Cooking Modes |
Convection Bake, Convection Bake Multi-Rack, Convection Broil Hi/Lo, Convection Roast, No-Preheat Air Frying, Precision Cooking Modes, Proof, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode, Warming |
| Cutout Depth (in) |
23.5 |
| OU Certified |
No |
| App Filter - Cleaning Type |
Steam and Self-Clean |
| Electrical Requirements |
208/240V ; 60Hz ; 40A |
| Optional Kits |
CXWDFHKPMBT Brushed Black, CXWDFHKPMBZ Brushed Bronze, CXWDFHKPMCG Brushed Brass, CXWDFHKPMCU Brushed Copper, CXWDFHKPMFB Flat Black, CXWDFHKPMSS Brushed Stainless |
| App Filter - Fuel Type |
Electric |
| App Filter - Convection |
Yes |
| Overall Depth |
26.75 in |
| KW Rating at 240V |
9 |
| Configuration |
French Door |
| Cutout Dimensions (w x h x d) (in.) |
28-1/2 x 51-13/16 x 23-1/2 (with pedestal rails); 28-1/2 x 50-1/4 x 23-1/2 (without pedestal rails) |
