Cooking Technology
Convection
Control Type
7" Full-Color Touch LCD Screen
Cutout Width (in)
28.5 in
Oven Cooking Modes
Convection Bake, Convection Bake Multi-Rack, Convection Broil Hi/Lo, Convection Roast, No Preheat Air Fry, Precision Cooking Modes, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode
Air Fry Basket
Optional- JXAFTRAY1VSS
Connected Capabilities
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant
Color Appearance
Matte Black
Installation
Above Warming Drawer, Side-by-Side
Cooking System
True European Convection with Direct Air (Both Ovens)
App Filter - Cabinet Width
Cooking 30 in. (Standard)
Approximate Shipping Weight
278 lb
Depth with Door Open
48.75 in
Optional Accessories
UXWORXR30 - 30" Never Scrub Roller Rack
Parts Warranty
Limited 1-year entire appliance
App Filter - Product Type
Wall Oven Double
Oven Rack Features
2 Self-Clean Roller Racks (Both Ovens), Embossed Rack Positions (Both Ovens)
App Filter - Convection
Yes
Overall Height
51.0625 in
Total Capacity (cubic feet)
10 cu ft
Self-Clean Oven Door Lock
Automatic
Cleaning Time
Variable with Delay Clean Option
Configuration
Double Oven
Oven Door Features
Big View Oven Window, Soft-Close Hinges
Oven Interior Dimensions (upper)
25 x 17-3/8 x 20-1/4
App Filter - Cleaning Type
Steam and Self-Clean
Oven Interior Dimensions (lower)
25 x 17-3/8 x 20-1/4
App Filter - Fuel Type
Electric
Oven Features
10-Pass Bake Element, 10-Pass Dual Broil Element, Closed Door Broiling
App Filter - Control Type
Electronic touchpad
App Filter - Cooking Technology
Convection
Handle Color
Brushed Stainless
Optional Kits
CXWD0H0PMBT Brushed Black, CXWD0H0PMBZ Brushed Bronze, CXWD0H0PMCG Brushed Brass, CXWD0H0PMCU Brushed Copper, CXWD0H0PMFB Flat Black, CXWD0H0PMSS Brushed Stainless
Cutout Height (in)
51.8125 in
Oven Interior
2 Halogen Interior Oven Lights (Both Ovens), Black Gloss Finish, Hidden Bake
Handle
Café Pro Style, Customizable
Oven Control Features
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Dehydration, Delay Time, Electronic Clock & Kitchen Timer, Mis-Wire Detection, Oven Camera, Proof Mode, Remote Enabled, Sabbath Mode, Scan-to-cook, Temperature Probe, Warm Mode
Electrical Requirements
208/240V ; 60Hz ; 40A
Capacity (Cu. Ft.)
5.0 Upper / 5.0 Lower
Warranty Notes
See written warranty for full details
Oven Rack Positions (Single or Upper/Lower)
6 / 6
App Filter - WiFi Connect
Built-In
Oven Cleaning Type
Self-Clean with Steam Clean Option
Labor Warranty
Limited 1-year entire appliance
Cutout Dimensions (w x h x d) (in.)
28-1/2 x 51-13/16 x 23-1/2
| Cabinet Width |
30 in |
| Cooking Technology |
Convection |
| Control Type |
7" Full-Color Touch LCD Screen |
| Bake Wattage |
2850W |
| Cutout Width (in) |
28.5 in |
| Oven Cooking Modes |
Convection Bake, Convection Bake Multi-Rack, Convection Broil Hi/Lo, Convection Roast, No Preheat Air Fry, Precision Cooking Modes, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode |
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| Connected Capabilities |
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant |
| Sabbath Mode |
Yes |
| Product Type |
Double Oven |
| Color Appearance |
Matte Black |
| Installation |
Above Warming Drawer, Side-by-Side |
| Cooking System |
True European Convection with Direct Air (Both Ovens) |
| KW Rating at 240V |
9 |
| App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
| Overall Width |
29.75 in |
| Approximate Shipping Weight |
278 lb |
| KW Rating at 208V |
6.8 |
| Cutout Depth (in) |
23.5 |
| Depth with Door Open |
48.75 in |
| Optional Accessories |
UXWORXR30 - 30" Never Scrub Roller Rack |
| Parts Warranty |
Limited 1-year entire appliance |
| App Filter - Product Type |
Wall Oven Double |
| Oven Rack Features |
2 Self-Clean Roller Racks (Both Ovens), Embossed Rack Positions (Both Ovens) |
| App Filter - Convection |
Yes |
| Overall Height |
51.0625 in |
| Total Capacity (cubic feet) |
10 cu ft |
| Self-Clean Oven Door Lock |
Automatic |
| Cleaning Time |
Variable with Delay Clean Option |
| Configuration |
Double Oven |
| Oven Door Features |
Big View Oven Window, Soft-Close Hinges |
| Oven Interior Dimensions (upper) |
25 x 17-3/8 x 20-1/4 |
| App Filter - Cleaning Type |
Steam and Self-Clean |
| Oven Interior Dimensions (lower) |
25 x 17-3/8 x 20-1/4 |
| App Filter - Fuel Type |
Electric |
| Amp Rating at 208V |
40 |
| Oven Features |
10-Pass Bake Element, 10-Pass Dual Broil Element, Closed Door Broiling |
| App Filter - Control Type |
Electronic touchpad |
| App Filter - Cooking Technology |
Convection |
| Convection Wattage |
2400W |
| OU Certified |
No |
| Handle Color |
Brushed Stainless |
| Optional Kits |
CXWD0H0PMBT Brushed Black, CXWD0H0PMBZ Brushed Bronze, CXWD0H0PMCG Brushed Brass, CXWD0H0PMCU Brushed Copper, CXWD0H0PMFB Flat Black, CXWD0H0PMSS Brushed Stainless |
| Cutout Height (in) |
51.8125 in |
| Oven Interior |
2 Halogen Interior Oven Lights (Both Ovens), Black Gloss Finish, Hidden Bake |
| Broiler Wattage |
4300W |
| Handle |
Café Pro Style, Customizable |
| Hertz |
60 |
| Oven Control Features |
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Dehydration, Delay Time, Electronic Clock & Kitchen Timer, Mis-Wire Detection, Oven Camera, Proof Mode, Remote Enabled, Sabbath Mode, Scan-to-cook, Temperature Probe, Warm Mode |
| Fuel Type |
Electric |
| Electrical Requirements |
208/240V ; 60Hz ; 40A |
| WiFi Connect |
Built-In |
| Capacity (Cu. Ft.) |
5.0 Upper / 5.0 Lower |
| Amp Rating at 240V |
40 |
| Warranty Notes |
See written warranty for full details |
| Overall Depth |
26.75 in |
| Oven Rack Positions (Single or Upper/Lower) |
6 / 6 |
| App Filter - WiFi Connect |
Built-In |
| Oven Cleaning Type |
Self-Clean with Steam Clean Option |
| Labor Warranty |
Limited 1-year entire appliance |
| Cutout Dimensions (w x h x d) (in.) |
28-1/2 x 51-13/16 x 23-1/2 |
