Oven Rack Positions (Single or Upper/Lower)
6
Cutout Height (in)
42.25 in
Cutout Dimensions (w x h x d) (in.)
28-5/8 x 42-1/4 x 23-1/2
Installation
Above Warming Drawer
Parts Warranty
Limited 1-year entire appliance
Cutout Width (in)
28.625 in
Oven Features
10-Pass Bake Element, 8-Pass Broil Element
Product Type
5-in-1 Oven, Double Oven, Microwave Oven Combination
Cooking System
True European Convection (Lower)
Handle Color
Brushed Stainless
Electrical Requirements
208/240V ; 60Hz ; 30A
Configuration
Double Oven
Oven Cleaning Type
Self-Clean with Steam Clean Option (Lower)
Advantium Cooking Modes
Convection Bake (Upper), Microwave (Upper), Proof (Upper), Speedcook (Upper), Warm (Upper)
App Filter - Cabinet Width
Cooking 30 in. (Standard)
Approximate Shipping Weight
235 lb
Capacity (Cu. Ft.)
1.7 Upper / 5.0 Lower
Electrical Input - 120V Watts
1800
Microwave Sensor Cooking Controls
Cook, Defrost, Express, Reheat
Baking/Speed Cook Pan
Porcelain (Upper)
Electrical Input - 120V Amperage
15
Oven Interior Dimensions (upper)
20-1/16 x 8-1/2 x 17
Cleaning Time
Variable with Delay Clean Option (Lower)
Cooking Technology
Advantium
Warranty Notes
See written warranty for full details
Color Appearance
Stainless Steel
App Filter - Cooking Technology
Advantium, Convection
Control Type
Dial, Glass Touch
App Filter - Fuel Type
Electric
Program Cooking
Over 175 Programmed Menu Selections
Microwave Watts (IEC-705)
1000 W
Oven Rack Features
1 Self-Clean Heavy-Duty Roller Rack, 2 Self-Clean Heavy-Duty Oven Racks, Ladder-Rack Positions (Lower)
Total Capacity (cubic feet)
6.7 cu ft
Oven Interior Dimensions (lower)
25 x 17-3/8 x 20-1/4
Self-Clean Oven Door Lock
Automatic (Lower)
App Filter - Cleaning Type
Steam and Self-Clean
App Filter - Product Type
Wall Oven Microwave Oven Combination
Oven Control Features
Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, C° or F° Programmable, Defrost Mode, Delay Clean Option, Delay Start, Electronic Clock & Kitchen Timer (Lower), Hi / Low Broil, Proof Mode, Sabbath Mode, Temperature Probe, Warm Mode
App Filter - Control Type
Electronic touchpad
App Filter - Convection
Yes
Oven Cooking Modes
Convection Bake (Lower Oven), Convection Bake Multi/Single Rack (Lower), Convection Broil (Lower), Convection Roast (Lower Oven)
Optional Kits
CXWD0H0PMBT Brushed Black, CXWD0H0PMBZ Brushed Bronze, CXWD0H0PMCG - Brushed Brass, CXWD0H0PMCU Brushed Copper, CXWD0H0PMFB - Flat Black, CXWD0H0PMSS Brushed Stainless
Oven Interior
1 Halogen Interior Oven Light (Upper), 2 Halogen Interior Oven Lights (Lower), Hidden Bake
Labor Warranty
Limited 1-year entire appliance
| Oven Rack Positions (Single or Upper/Lower) |
6 |
| Cutout Height (in) |
42.25 in |
| Broiler Wattage |
3400W |
| Handle Design |
Café Pro |
| Cutout Dimensions (w x h x d) (in.) |
28-5/8 x 42-1/4 x 23-1/2 |
| Installation |
Above Warming Drawer |
| Parts Warranty |
Limited 1-year entire appliance |
| Overall Width |
29.75 in |
| Cutout Width (in) |
28.625 in |
| Oven Features |
10-Pass Bake Element, 8-Pass Broil Element |
| Product Type |
5-in-1 Oven, Double Oven, Microwave Oven Combination |
| Cooking System |
True European Convection (Lower) |
| Handle Color |
Brushed Stainless |
| Fuel Type |
Electric |
| OU Certified |
No |
| Electrical Requirements |
208/240V ; 60Hz ; 30A |
| KW Rating at 240V |
7.2 |
| Configuration |
Double Oven |
| Oven Cleaning Type |
Self-Clean with Steam Clean Option (Lower) |
| Cabinet Width |
30 in |
| Advantium Cooking Modes |
Convection Bake (Upper), Microwave (Upper), Proof (Upper), Speedcook (Upper), Warm (Upper) |
| Sabbath Mode |
Yes |
| Cutout Depth (in) |
23.5 |
| Power Levels |
10 |
| App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
| Bake Wattage |
2850W |
| Approximate Shipping Weight |
235 lb |
| Net Weight |
215 lb |
| Capacity (Cu. Ft.) |
1.7 Upper / 5.0 Lower |
| Electrical Input - 120V Watts |
1800 |
| Microwave Sensor Cooking Controls |
Cook, Defrost, Express, Reheat |
| Turntable Size |
16 in |
| Baking/Speed Cook Pan |
Porcelain (Upper) |
| Electrical Input - 120V Amperage |
15 |
| Oven Interior Dimensions (upper) |
20-1/16 x 8-1/2 x 17 |
| Cleaning Time |
Variable with Delay Clean Option (Lower) |
| Cooking Technology |
Advantium |
| Warranty Notes |
See written warranty for full details |
| Color Appearance |
Stainless Steel |
| Style |
Built-In |
| Amp Rating at 208V |
30 |
| App Filter - Cooking Technology |
Advantium, Convection |
| Control Type |
Dial, Glass Touch |
| App Filter - Fuel Type |
Electric |
| Overall Depth |
26.75 in |
| Program Cooking |
Over 175 Programmed Menu Selections |
| Microwave Watts (IEC-705) |
1000 W |
| KW Rating at 208V |
5.4 |
| Oven Rack Features |
1 Self-Clean Heavy-Duty Roller Rack, 2 Self-Clean Heavy-Duty Oven Racks, Ladder-Rack Positions (Lower) |
| Convection Wattage |
2400W |
| Total Capacity (cubic feet) |
6.7 cu ft |
| Oven Interior Dimensions (lower) |
25 x 17-3/8 x 20-1/4 |
| Self-Clean Oven Door Lock |
Automatic (Lower) |
| App Filter - Cleaning Type |
Steam and Self-Clean |
| App Filter - Product Type |
Wall Oven Microwave Oven Combination |
| Oven Control Features |
Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, C° or F° Programmable, Defrost Mode, Delay Clean Option, Delay Start, Electronic Clock & Kitchen Timer (Lower), Hi / Low Broil, Proof Mode, Sabbath Mode, Temperature Probe, Warm Mode |
| Cookbook |
Yes (Advantium) |
| App Filter - Control Type |
Electronic touchpad |
| App Filter - Convection |
Yes |
| Oven Cooking Modes |
Convection Bake (Lower Oven), Convection Bake Multi/Single Rack (Lower), Convection Broil (Lower), Convection Roast (Lower Oven) |
| Amp Rating at 240V |
30 |
| Optional Kits |
CXWD0H0PMBT Brushed Black, CXWD0H0PMBZ Brushed Bronze, CXWD0H0PMCG - Brushed Brass, CXWD0H0PMCU Brushed Copper, CXWD0H0PMFB - Flat Black, CXWD0H0PMSS Brushed Stainless |
| Overall Height |
42.375 in |
| Oven Interior |
1 Halogen Interior Oven Light (Upper), 2 Halogen Interior Oven Lights (Lower), Hidden Bake |
| Labor Warranty |
Limited 1-year entire appliance |
