App Filter - Control Type
Electronic touchpad
Air Fry Basket
Optional- JXAFTRAY1VSS
App Filter - Cleaning Type
Steam and Self-Clean
App Filter - Product Type
Wall Oven Single
Oven Cooking Modes
Convection Bake, Convection Bake Multi-Rack, Convection Roast, Keep Warm, No Preheat Air Fry, Proof, Scan-to-Cook, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode
Color Appearance
Stainless Steel
Handle Color
Brushed Stainless
Oven Rack Features
1 Never Scrub Flat Rack, 1 Never Scrub Roller Rack, Embossed Rack Positions
Oven Rack Positions (Single or Upper/Lower)
6
Oven Door Features
Big View Oven Window
Control Type
7" Full-Color Touch LCD Screen
Self-Clean Oven Door Lock
Automatic
Oven Cleaning Type
Self-Clean with Steam Clean Option
App Filter - Fuel Type
Electric
Configuration
Single Oven
App Filter - Cabinet Width
Cooking 27 in.
Total Capacity (cubic feet)
4.3 cu ft
Handle
Café Pro Style, Customizable
Electrical Requirements
208/240V ; 60Hz ; 20A
Connected Capabilities
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant
Optional Accessories
UXWORXR27 - 27" Never Scrub Roller Rack, WB18T10578 - 72" Electrical Conduit, WB18T10581 - 60" Electrical Conduit, WB48X10056 - Large Broiler Pan
Cleaning Time
Variable with Delay Clean Option
App Filter - Cooking Technology
Convection
Cooking System
True European Convection
Oven Control Features
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Delay Time, Electronic Clock & Kitchen Timer, Remote Enabled, Sabbath Mode, Temperature Probe
Cooking Technology
Convection
Parts Warranty
Limited 1-year entire appliance
Optional Kits
CXWS7H0PNBT - Brushed Black, CXWS7H0PNBZ - Brushed Bronze, CXWS7H0PNCG - Brushed Brass, CXWS7H0PNCU - Brushed Copper, CXWS7H0PNFB - Flat Black, CXWS7H0PNSS - Brushed Stainless
Approximate Shipping Weight
135 lb
App Filter - WiFi Connect
Built-In
App Filter - Convection
Yes
Installation
Above Warming Drawer, Side-by-Side, Under Built-In Advantium, Under Built-In Microwave, Under Cooktop, Undercounter
Cutout Height (in)
27.625 in
Labor Warranty
Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Oven Features
10-Pass Bake Element, 8-Pass Broil Element, Closed Door Broiling
Oven Interior
2 Halogen Interior Oven Lights, Black Gloss Finish, Hidden Bake
Cutout Dimensions (w x h x d) (in.)
25-1/4 x 27-5/8 x 23-1/2
Cutout Width (in)
25.25 in
Oven Interior Dimensions (W x H x D) (in.)
21-1/2 x 17-1/4 x 20
| Overall Width |
26.75 in |
| Bake Wattage |
2600W |
| Broiler Wattage |
3400W |
| App Filter - Control Type |
Electronic touchpad |
| Product Type |
Single Oven |
| Cabinet Width |
27 in |
| Air Fry Basket |
Optional- JXAFTRAY1VSS |
| App Filter - Cleaning Type |
Steam and Self-Clean |
| App Filter - Product Type |
Wall Oven Single |
| KW Rating at 240V |
3.6 |
| KW Rating at 208V |
2.7 |
| Overall Height |
28.75 in |
| Oven Cooking Modes |
Convection Bake, Convection Bake Multi-Rack, Convection Roast, Keep Warm, No Preheat Air Fry, Proof, Scan-to-Cook, Thermal Bake, Thermal Broil Hi/Lo, Turkey Mode |
| Color Appearance |
Stainless Steel |
| OU Certified |
No |
| Handle Color |
Brushed Stainless |
| Oven Rack Features |
1 Never Scrub Flat Rack, 1 Never Scrub Roller Rack, Embossed Rack Positions |
| Oven Rack Positions (Single or Upper/Lower) |
6 |
| Oven Door Features |
Big View Oven Window |
| Control Type |
7" Full-Color Touch LCD Screen |
| Overall Depth |
26.625 in |
| Self-Clean Oven Door Lock |
Automatic |
| Cutout Depth (in) |
23.5 |
| Oven Cleaning Type |
Self-Clean with Steam Clean Option |
| App Filter - Fuel Type |
Electric |
| Fuel Type |
Electric |
| Configuration |
Single Oven |
| App Filter - Cabinet Width |
Cooking 27 in. |
| Total Capacity (cubic feet) |
4.3 cu ft |
| Electrical Requirements |
208/240V ; 60Hz ; 20A |
| Connected Capabilities |
Amazon Alexa, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant |
| Optional Accessories |
UXWORXR27 - 27" Never Scrub Roller Rack, WB18T10578 - 72" Electrical Conduit, WB18T10581 - 60" Electrical Conduit, WB48X10056 - Large Broiler Pan |
| Cleaning Time |
Variable with Delay Clean Option |
| App Filter - Cooking Technology |
Convection |
| Net Weight |
120 lb |
| Cooking System |
True European Convection |
| Oven Control Features |
12-Hour Shut-Off Capability, Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, Cook Time, C° or F° Programmable, Delay Time, Electronic Clock & Kitchen Timer, Remote Enabled, Sabbath Mode, Temperature Probe |
| Cooking Technology |
Convection |
| Parts Warranty |
Limited 1-year entire appliance |
| Optional Kits |
CXWS7H0PNBT - Brushed Black, CXWS7H0PNBZ - Brushed Bronze, CXWS7H0PNCG - Brushed Brass, CXWS7H0PNCU - Brushed Copper, CXWS7H0PNFB - Flat Black, CXWS7H0PNSS - Brushed Stainless |
| Approximate Shipping Weight |
135 lb |
| App Filter - WiFi Connect |
Built-In |
| App Filter - Convection |
Yes |
| Installation |
Above Warming Drawer, Side-by-Side, Under Built-In Advantium, Under Built-In Microwave, Under Cooktop, Undercounter |
| Convection Wattage |
2400W |
| WiFi Connect |
Built-In |
| Cutout Height (in) |
27.625 in |
| Labor Warranty |
Limited 1-year entire appliance |
| Warranty Notes |
See written warranty for full details |
| Oven Features |
10-Pass Bake Element, 8-Pass Broil Element, Closed Door Broiling |
| Amp Rating at 240V |
20 |
| Oven Interior |
2 Halogen Interior Oven Lights, Black Gloss Finish, Hidden Bake |
| Cutout Dimensions (w x h x d) (in.) |
25-1/4 x 27-5/8 x 23-1/2 |
| Cutout Width (in) |
25.25 in |
| Sabbath Mode |
Yes |
| Amp Rating at 208V |
20 |
| Oven Interior Dimensions (W x H x D) (in.) |
21-1/2 x 17-1/4 x 20 |
