Icemaker
Factory-Installed
Freezer Features
Freezer Drawer with Full Extension Slides, Soft-Close
Color Appearance
Stainless Steel
Labor Warranty
Limited 1-year entire appliance
Freezer Capacity
3.45 cu ft
Volts/Hertz/Amps
115V; 60Hz; 20A
Connected Capabilities
Amazon Alexa, Google Home
Convertible Drawer Capacity
2.91 cu ft
Handle Color
Brushed Stainless
Exterior Style
Built-In, Standard Depth
Defrost Type
Automatic Defrost
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 1-year entire appliance, Limited 5-year sealed refrigerating system
Temperature Display
Internal Digital
Exterior Design
Smooth Doors
Leveling System
4 Point (2 adjustable back rollers, 2 adjustable front legs)
Product Type
Bottom Freezer Refrigerator, Built-In Refrigerator, French-Door Refrigerator
Fresh Food Door Bins
6 Full-Width, Adjustable
Total Capacity (cubic feet)
20.1 cu ft
Fresh Food Features
Display Temp Setpoint, Door Alarm, Filter-Change Indicator, Interior Lighting - Ramp Up LED 4, Sabbath Mode Status
Fresh Food Cabinet Drawers
2 Half-Width Adjustable Climate Zone Drawers, Copper Accents, Full-Extension Soft-Close Slides
Fresh Food Door Features
6 Adjustable, Copper Accents, Full-Width, Plastic
Water Filtration
GE Water Filtration (XWFE Filter)
Fresh Food Capacity
13.69 cu ft
Height to Top of Hinge
83.5 in
Configuration
French Door & Double Drawer
Energy Consumption (kWh/year)
654
Depth Without Handle
24.75 in
Optional Kits
CXSB4H4PVBT - Brushed Black, CXSB4H4PVBZ - Brushed Bronze, CXSB4H4PVCG - Brushed Brass, CXSB4H4PVCU - Brushed Copper, CXSB4H4PVFB - Flat Black
Installation
Fully Integrated Installation
Middle Drawer
4 Settings (Hard Freeze [sync w/freezer], Meats, Cold Beverages, FF/Snack, Yes, Convertible; Plastic Interior
Side by Side Install Toe-Kick Kit
72" ZKK72R
SxS Install Heater/Unification Kit
ZKMV
Temperature Management Features
Dual Evaporator, Independent Temperature Controls
Height to Top of Case
83.6875 in
Bottom Drawer
One Adjustable Divider, Plastic Interior, Yes, Freezer w/IM
Control Type
Integrated, Upfront Capacitance Touch Controls
Fresh Food Cabinet Shelves
6 Half-Width, Copper Trim, Glass
Overall Depth with Handle
27.3125 in
OU Certified
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately
Filter Change Indicator
Display water filter status @ 90% usage
Trim Kit
36" Trim Kit for 24" deep cabinets ZKW36V, 72" Trim Kit for 24" deep cabinets ZKW72V
Door Stops
90 Degree and 115 Degree
Approximate Shipping Weight
621 lb
| Icemaker |
Factory-Installed |
| Door Alarm |
Yes |
| Freezer Features |
Freezer Drawer with Full Extension Slides, Soft-Close |
| Sabbath Mode |
Yes |
| Color Appearance |
Stainless Steel |
| Labor Warranty |
Limited 1-year entire appliance |
| Freezer Capacity |
3.45 cu ft |
| Volts/Hertz/Amps |
115V; 60Hz; 20A |
| Net Weight |
562 lb |
| Connected Capabilities |
Amazon Alexa, Google Home |
| Convertible Drawer Capacity |
2.91 cu ft |
| Handle Color |
Brushed Stainless |
| Exterior Style |
Built-In, Standard Depth |
| Defrost Type |
Automatic Defrost |
| Warranty Notes |
See written warranty for full details |
| Quiet Package |
36 dBA |
| Overall Width |
35.75 in |
| Parts Warranty |
Limited 1-year entire appliance, Limited 5-year sealed refrigerating system |
| Overall Depth |
24.75 in |
| Temperature Display |
Internal Digital |
| Exterior Design |
Smooth Doors |
| Leveling System |
4 Point (2 adjustable back rollers, 2 adjustable front legs) |
| Product Type |
Bottom Freezer Refrigerator, Built-In Refrigerator, French-Door Refrigerator |
| Fresh Food Door Bins |
6 Full-Width, Adjustable |
| Total Capacity (cubic feet) |
20.1 cu ft |
| Fresh Food Features |
Display Temp Setpoint, Door Alarm, Filter-Change Indicator, Interior Lighting - Ramp Up LED 4, Sabbath Mode Status |
| Fresh Food Cabinet Drawers |
2 Half-Width Adjustable Climate Zone Drawers, Copper Accents, Full-Extension Soft-Close Slides |
| Fresh Food Door Features |
6 Adjustable, Copper Accents, Full-Width, Plastic |
| Water Filtration |
GE Water Filtration (XWFE Filter) |
| Fresh Food Capacity |
13.69 cu ft |
| Height to Top of Hinge |
83.5 in |
| WiFi Connect |
Built-In |
| Adjustable Rollers |
2 |
| Energy Consumption (kWh/year) |
654 |
| Depth Without Handle |
24.75 in |
| Optional Kits |
CXSB4H4PVBT - Brushed Black, CXSB4H4PVBZ - Brushed Bronze, CXSB4H4PVCG - Brushed Brass, CXSB4H4PVCU - Brushed Copper, CXSB4H4PVFB - Flat Black |
| Interior Lighting |
LED |
| Installation |
Fully Integrated Installation |
| Middle Drawer |
4 Settings (Hard Freeze [sync w/freezer], Meats, Cold Beverages, FF/Snack, Yes, Convertible; Plastic Interior |
| Side by Side Install Toe-Kick Kit |
72" ZKK72R |
| SxS Install Heater/Unification Kit |
ZKMV |
| Temperature Management Features |
Dual Evaporator, Independent Temperature Controls |
| Case Color |
Gray |
| Overall Height |
83.5 in |
| Height to Top of Case |
83.6875 in |
| Refrigerant Type |
R600a |
| Bottom Drawer |
One Adjustable Divider, Plastic Interior, Yes, Freezer w/IM |
| Control Type |
Integrated, Upfront Capacitance Touch Controls |
| Fresh Food Cabinet Shelves |
6 Half-Width, Copper Trim, Glass |
| Number of Doors |
3 |
| Dispenser |
Non-Dispenser |
| Overall Depth with Handle |
27.3125 in |
| Door Style |
Solid Door |
| OU Certified |
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately |
| Filter Change Indicator |
Display water filter status @ 90% usage |
| Coil-Free Back |
Yes |
| Door Swing |
French Door |
| Trim Kit |
36" Trim Kit for 24" deep cabinets ZKW36V, 72" Trim Kit for 24" deep cabinets ZKW72V |
| Door Stops |
90 Degree and 115 Degree |
| Hidden Door Hinge(s) |
Yes |
| Approximate Shipping Weight |
621 lb |
