Control Type
Integrated, Upfront Capacitance Touch Controls
Product Type
Bottom Freezer Refrigerator, Built-In Refrigerator, French-Door Refrigerator
Door Stops
90 Degree and 115 Degree
SxS Install Heater/Unification Kit
ZKMV
Connected Capabilities
Amazon Alexa, Google Home
Total Capacity (cubic feet)
20.1 cu ft
Defrost Type
Automatic Defrost
Configuration
French Door & Double Drawer
Fresh Food Cabinet Drawers
2 Half-Width Adjustable Climate Zone Drawers, Copper Accents, Full-Extension Soft-Close Slides
Height to Top of Hinge
83.5 in
Trim Kit
36" Trim Kit for 24" deep cabinets ZKW36V, 72" Trim Kit for 24" deep cabinets ZKW72V
Warranty Notes
Limited 5-year Sealed System, See written warranty for details
Fresh Food Capacity
13.69 cu ft
Exterior Style
Built-In, Standard Depth
Middle Drawer
4 Settings (Hard Freeze [sync w/freezer], Meats, Cold Beverages, FF/Snack, Yes, Convertible; Plastic Interior
Approximate Shipping Weight
621 lb
Fresh Food Door Features
6 Adjustable, Copper Accents, Full-Width, Plastic
Labor Warranty
Limited 1-year entire appliance
Temperature Management Features
Dual Evaporator, Independent Temperature Controls
Overall Depth with Handle
27.3125 in
Fresh Food Features
Display Temp Setpoint, Door Alarm, Filter-Change Indicator, Interior Lighting - Ramp Up LED 4, Sabbath Mode Status
Energy Consumption (kWh/year)
654
Parts Warranty
Limited 1-year entire appliance
OU Certified
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately
Filter Change Indicator
Display water filter status @ 90% usage
Installation
Fully Integrated Installation
Depth Without Handle
24.75 in
Optional Kits
CXSB4H4PVBT - Brushed Black, CXSB4H4PVBZ - Brushed Bronze, CXSB4H4PVCG - Brushed Brass, CXSB4H4PVCU - Brushed Copper, CXSB4H4PVFB - Flat Black
Leveling System
4 Point (2 adjustable back rollers, 2 adjustable front legs)
Side by Side Install Toe-Kick Kit
72" ZKK72R
Temperature Display
Internal Digital
Convertible Drawer Capacity
2.91 cu ft
Handle Color
Brushed Stainless
Icemaker
Factory-Installed
Fresh Food Door Bins
6 Full-Width, Adjustable
Color Appearance
Stainless Steel
Water Filtration
GE Water Filtration (XWFE Filter)
Volts/Hertz/Amps
115V; 60Hz; 20A
Height to Top of Case
83.6875 in
Exterior Design
Smooth Doors
Fresh Food Cabinet Shelves
6 Half-Width, Copper Trim, Glass
Bottom Drawer
One Adjustable Divider, Plastic Interior, Yes, Freezer w/IM
Freezer Features
Freezer Drawer with Full Extension Slides, Soft-Close
Freezer Capacity
3.45 cu ft
| Control Type |
Integrated, Upfront Capacitance Touch Controls |
| Product Type |
Bottom Freezer Refrigerator, Built-In Refrigerator, French-Door Refrigerator |
| Door Stops |
90 Degree and 115 Degree |
| SxS Install Heater/Unification Kit |
ZKMV |
| Connected Capabilities |
Amazon Alexa, Google Home |
| Overall Height |
83.5 in |
| Total Capacity (cubic feet) |
20.1 cu ft |
| Net Weight |
562 lb |
| Defrost Type |
Automatic Defrost |
| Configuration |
French Door & Double Drawer |
| Fresh Food Cabinet Drawers |
2 Half-Width Adjustable Climate Zone Drawers, Copper Accents, Full-Extension Soft-Close Slides |
| Number of Doors |
3 |
| Height to Top of Hinge |
83.5 in |
| Door Swing |
French Door |
| Trim Kit |
36" Trim Kit for 24" deep cabinets ZKW36V, 72" Trim Kit for 24" deep cabinets ZKW72V |
| Warranty Notes |
Limited 5-year Sealed System, See written warranty for details |
| Fresh Food Capacity |
13.69 cu ft |
| Exterior Style |
Built-In, Standard Depth |
| Middle Drawer |
4 Settings (Hard Freeze [sync w/freezer], Meats, Cold Beverages, FF/Snack, Yes, Convertible; Plastic Interior |
| Dispenser |
Non-Dispenser |
| Overall Width |
35.75 in |
| Sabbath Mode |
Yes |
| Approximate Shipping Weight |
621 lb |
| Fresh Food Door Features |
6 Adjustable, Copper Accents, Full-Width, Plastic |
| Labor Warranty |
Limited 1-year entire appliance |
| Temperature Management Features |
Dual Evaporator, Independent Temperature Controls |
| Overall Depth with Handle |
27.3125 in |
| Fresh Food Features |
Display Temp Setpoint, Door Alarm, Filter-Change Indicator, Interior Lighting - Ramp Up LED 4, Sabbath Mode Status |
| Energy Consumption (kWh/year) |
654 |
| Parts Warranty |
Limited 1-year entire appliance |
| WiFi Connect |
Built-In |
| Coil-Free Back |
Yes |
| OU Certified |
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately |
| Filter Change Indicator |
Display water filter status @ 90% usage |
| Installation |
Fully Integrated Installation |
| Depth Without Handle |
24.75 in |
| Optional Kits |
CXSB4H4PVBT - Brushed Black, CXSB4H4PVBZ - Brushed Bronze, CXSB4H4PVCG - Brushed Brass, CXSB4H4PVCU - Brushed Copper, CXSB4H4PVFB - Flat Black |
| Leveling System |
4 Point (2 adjustable back rollers, 2 adjustable front legs) |
| Side by Side Install Toe-Kick Kit |
72" ZKK72R |
| Temperature Display |
Internal Digital |
| Convertible Drawer Capacity |
2.91 cu ft |
| Handle Color |
Brushed Stainless |
| Hidden Door Hinge(s) |
Yes |
| Icemaker |
Factory-Installed |
| Fresh Food Door Bins |
6 Full-Width, Adjustable |
| Color Appearance |
Stainless Steel |
| Water Filtration |
GE Water Filtration (XWFE Filter) |
| Refrigerant Type |
R600a |
| Volts/Hertz/Amps |
115V; 60Hz; 20A |
| Overall Depth |
24.75 in |
| Height to Top of Case |
83.6875 in |
| Exterior Design |
Smooth Doors |
| Adjustable Rollers |
2 |
| Case Color |
Gray |
| Fresh Food Cabinet Shelves |
6 Half-Width, Copper Trim, Glass |
| Bottom Drawer |
One Adjustable Divider, Plastic Interior, Yes, Freezer w/IM |
| Quiet Package |
36 dBA |
| Door Alarm |
Yes |
| Interior Lighting |
LED |
| Freezer Features |
Freezer Drawer with Full Extension Slides, Soft-Close |
| Freezer Capacity |
3.45 cu ft |
