Temperature Display
Internal Digital
Side by Side Install Toe-Kick Kit
72" ZKK72R
Trim Kit
36" Trim Kit for 24" deep cabinets ZKW36V, 72" Trim Kit for 24" deep cabinets ZKW72V
Freezer Features
Freezer Drawer with Full Extension Slides, Soft-Close
Leveling System
4 Point (2 adjustable back rollers, 2 adjustable front legs)
Defrost Type
Automatic Defrost
Product Type
Bottom Freezer Refrigerator, Built-In Refrigerator
Total Capacity (cubic feet)
20.1 cu ft
Configuration
Full Door and Double Drawer
Control Type
Integrated, Upfront Capacitance Touch Controls
Optional Kits
CXSB3H3PVBT - Brushed Black, CXSB3H3PVBZ - Brushed Bronze, CXSB3H3PVCG - Brushed Brass, CXSB3H3PVCU - Brushed Copper, CXSB3H3PVFB - Flat Black
Middle Drawer
4 Settings (Hard Freeze [sync w/freezer], Meats, Cold Beverages, FF/Snack, Yes, Convertible; Plastic Interior
Handle Color
Brushed Stainless
Parts Warranty
Limited 1-year entire appliance
Exterior Style
Built-In, Standard Depth
Color Appearance
Stainless Steel
Fresh Food Features
Display Temp Setpoint, Door Alarm, Filter-Change Indicator, Interior Lighting - Ramp Up LED 4, Sabbath Mode Status
Fresh Food Cabinet Drawers
2 Half-Width Adjustable Climate Zone Drawers, Copper Accents, Full-Extension Soft-Close Slides
Fresh Food Capacity
13.69 cu ft
Volts/Hertz/Amps
115V; 60Hz; 20A
Labor Warranty
Limited 1-year entire appliance
Door Stops
90 Degree and 115 Degree
Icemaker
Factory-Installed
Energy Consumption (kWh/year)
654
Installation
Fully Integrated Installation
Water Filtration
GE Water Filtration (XWFE Filter)
Temperature Management Features
Dual Evaporator, Independent Temperature Controls
Fresh Food Cabinet Shelves
4 Half-Width, Copper Trim, Glass
Bottom Drawer
One Adjustable Divider, Plastic Interior, Yes, Freezer w/IM
Freezer Capacity
3.45 cu ft
Approximate Shipping Weight
621 lb
Convertible Drawer Capacity
2.91 cu ft
Fresh Food Door Bins
3 Full-Width, Adjustable
Height to Top of Hinge
83.5 in
Exterior Design
Smooth Doors
Overall Depth with Handle
27.3125 in
Connected Capabilities
Amazon Alexa, Google Home
Depth Without Handle
24.75 in
Height to Top of Case
83.6875 in
Warranty Notes
Limited 5-year Sealed System, See written warranty for details
Fresh Food Door Features
3 Adjustable Bins, Copper Accents, Full-Width, Plastic
Filter Change Indicator
Display water filter status @ 90% usage
SxS Install Heater/Unification Kit
ZKMV
OU Certified
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately
| Temperature Display |
Internal Digital |
| Side by Side Install Toe-Kick Kit |
72" ZKK72R |
| Trim Kit |
36" Trim Kit for 24" deep cabinets ZKW36V, 72" Trim Kit for 24" deep cabinets ZKW72V |
| Freezer Features |
Freezer Drawer with Full Extension Slides, Soft-Close |
| Number of Doors |
4 |
| Leveling System |
4 Point (2 adjustable back rollers, 2 adjustable front legs) |
| WiFi Connect |
Built-In |
| Refrigerant Type |
R600a |
| Defrost Type |
Automatic Defrost |
| Product Type |
Bottom Freezer Refrigerator, Built-In Refrigerator |
| Total Capacity (cubic feet) |
20.1 cu ft |
| Configuration |
Full Door and Double Drawer |
| Quiet Package |
36 dBA |
| Control Type |
Integrated, Upfront Capacitance Touch Controls |
| Optional Kits |
CXSB3H3PVBT - Brushed Black, CXSB3H3PVBZ - Brushed Bronze, CXSB3H3PVCG - Brushed Brass, CXSB3H3PVCU - Brushed Copper, CXSB3H3PVFB - Flat Black |
| Middle Drawer |
4 Settings (Hard Freeze [sync w/freezer], Meats, Cold Beverages, FF/Snack, Yes, Convertible; Plastic Interior |
| Handle Color |
Brushed Stainless |
| Parts Warranty |
Limited 1-year entire appliance |
| Exterior Style |
Built-In, Standard Depth |
| Color Appearance |
Stainless Steel |
| Sabbath Mode |
Yes |
| Fresh Food Features |
Display Temp Setpoint, Door Alarm, Filter-Change Indicator, Interior Lighting - Ramp Up LED 4, Sabbath Mode Status |
| Fresh Food Cabinet Drawers |
2 Half-Width Adjustable Climate Zone Drawers, Copper Accents, Full-Extension Soft-Close Slides |
| Adjustable Rollers |
2 |
| Fresh Food Capacity |
13.69 cu ft |
| Coil-Free Back |
Yes |
| Volts/Hertz/Amps |
115V; 60Hz; 20A |
| Labor Warranty |
Limited 1-year entire appliance |
| Door Stops |
90 Degree and 115 Degree |
| Door Swing |
Right Swing |
| Icemaker |
Factory-Installed |
| Energy Consumption (kWh/year) |
654 |
| Door Style |
Solid Door |
| Installation |
Fully Integrated Installation |
| Water Filtration |
GE Water Filtration (XWFE Filter) |
| Temperature Management Features |
Dual Evaporator, Independent Temperature Controls |
| Fresh Food Cabinet Shelves |
4 Half-Width, Copper Trim, Glass |
| Case Color |
Gray |
| Bottom Drawer |
One Adjustable Divider, Plastic Interior, Yes, Freezer w/IM |
| Door Alarm |
Yes |
| Freezer Capacity |
3.45 cu ft |
| Approximate Shipping Weight |
621 lb |
| Convertible Drawer Capacity |
2.91 cu ft |
| Overall Height |
83.5 in |
| Fresh Food Door Bins |
3 Full-Width, Adjustable |
| Net Weight |
555 lb |
| Height to Top of Hinge |
83.5 in |
| Exterior Design |
Smooth Doors |
| Overall Depth with Handle |
27.3125 in |
| Dispenser |
Non-Dispenser |
| Connected Capabilities |
Amazon Alexa, Google Home |
| Depth Without Handle |
24.75 in |
| Height to Top of Case |
83.6875 in |
| Interior Lighting |
LED |
| Warranty Notes |
Limited 5-year Sealed System, See written warranty for details |
| Overall Width |
35.75 in |
| Overall Depth |
24.75 in |
| Fresh Food Door Features |
3 Adjustable Bins, Copper Accents, Full-Width, Plastic |
| Filter Change Indicator |
Display water filter status @ 90% usage |
| SxS Install Heater/Unification Kit |
ZKMV |
| OU Certified |
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, sold separately |
