Cooktop Burner Grate Color
Matte Black
Total Capacity (cubic feet)
7 cu ft
Lower Oven Features
Dual element bake
Oven Rack Features
1 Roller Rack (Upper), 2 Self-Clean Flat Oven Racks (Lower)
Connected Capabilities
Amazon Alexa, DiGiorno, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant
Grates
Included Center Grate
Air Fry Basket
Optional- JXAFTRAY1VSS
Oven Control Features
Audible Preheat Signal, Auto Oven Shut-Off, Auto Self Clean, Automatic Oven Timer (Time Bake), Chef Connect, Control Lock Capability, Delay Bake Option (Time Bake), Delay Clean Option, Digipad Numeric Entry, Electronic Clock and Timer, Front Controls, In-Oven Broiling, Sabbath Mode, Self-Clean Cool Down Time Display, Temperature Probe
Electrical Requirements
208/240V ; 60Hz ; 30A
Height to Top of Rear Vent Trim
37.375 in
Oven Cooking Modes
Baked Goods - Both Ovens, Convection Bake, Convection Roast, Frozen Pizza Multi Rack - Lower Oven, Frozen Pizza Single Rack - Lower Oven (No Preheat), Frozen Snacks Multi Rack - Lower Oven, Frozen Snacks Single Rack- Lower Oven (No Preheat), No Preheat Air Fry, Proof (Lower Oven), Warming (Both Ovens)
Trim Kit
JXFILLR1SS, Optional
Product Type
Slide-In Double Oven
Burner - Left Rear
5,000 BTU Precise Simmer
Oven Rack Positions (Single or Upper/Lower)
6
App Filter - Convection
Yes
LP Conversion Kit
Included
Ignition System
Electronic w/Auto Reignition
Oven Features
6-Pass Broil Element, 8-Pass Broil Element
Burner - Center
9,500 BTU Front / 9,500 BTU Rear
App Filter - Cooking Technology
Convection, Traditional
App Filter - Cabinet Width
Cooking 30 in. (Standard)
Configuration
Double Oven Range
Burner - Left Front
21,000 BTU Tri-ring Burner
App Filter - Product Type
Ranges Slide-In Double Oven
Fuel Type
240V Electric and Natural Gas
Depth with Door Open
43.875 in
Oven Interior
2 Oven Interior Lights, Black, Hidden Bake
Approximate Shipping Weight
291 lb
Oven Cleaning Type
Self-Clean with Steam Clean Option
Cleaning Time
Variable with Delay Clean Option
Cooking Technology
Traditional Upper; Convection Lower
Height to Cooking Surface (in.)
36 1/4 +/- 1/4
Burner - Right Rear
12,000 BTU
App Filter - Fuel Type
Dual Fuel
Power Connection
Power Cord - Not Included
Optional Kits
CXFCGHKPMBT Brushed Black, CXFCGHKPMBZ Brushed Bronze, CXFCGHKPMCG Brushed Brass, CXFCGHKPMCU Brushed Copper, CXFCGHKPMFB Flat Black, CXFCGHKPMSS Brushed Stainless
Burner - Right Front
15,000 BTU
Depth Without Handle
26.875 in
Control Type
Backlit, Glass Touch
Top Burner BTU Rating - LP (000's BTU's)
(1) 18.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0;
Warranty Notes
See written warranty for full details
Frameless Oven Door(s)
Stainless Steel
Installation
Flush Appearance, Free-standing cut-out, Power Cord Not Included
Grill
Integrated Cast Iron, JXCGRILL1, Optional
Self-Clean Oven Door Lock
Automatic
Top Burner BTU Rating - Nat. Gas (000's BTU's)
(1) 21.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0
Cooking System
True European Precise Air Reversing
Cooktop Type
Standard Grates
Cooktop Burner Grate Features
Heavy-Cast Edge-to-Edge Grates
Control Knobs
Brushed Bronze Appearance, Weighted
Leveling System
4 Leveling Legs
Cooktop Burner Grate Material
Cast-Iron
Handle Color
Brushed Bronze
Broiler Wattage
3000W Upper / 3600W Lower
App Filter - Cleaning Type
Self-Clean
Handle
Consumer Removable, Customizable, Professional Style
Control Location
Front controls
Color Appearance
Matte White
Dishwasher Safe Knobs
Yes
App Filter - Cooktop Type
Standard Grates
Cooktop Burner Type
Sealed
App Filter - Control Type
Electronic touchpad
App Filter - Tri-Ring Burner
Yes
Griddle
Included, Integrated Cast Iron
Cooktop Surface
Deep Recessed, Stainless Steel
Bake Wattage
2650W Upper / 2650W Lower
Volts/Hertz/Amps
208/240V; 60Hz; 30A
Oven Door Features
Big Clear View Oven Window, Matte White Frameless Oven Door
Capacity (Cu. Ft.)
2.7 Upper / 4.3 Lower
Labor Warranty
Limited 1-year entire appliance
Parts Warranty
Limited 1-year entire appliance
Oven Interior Dimensions (W x H x D) (in.)
24 x 10-1/8 x 19-1/8 - Upper; 24 x 15 x 20-5/8 - Lower
Valves (Degree of Turn)
270
Cooktop Burner Grate Color |
Matte Black |
Convection Wattage |
2500W |
Total Capacity (cubic feet) |
7 cu ft |
Lower Oven Features |
Dual element bake |
Oven Rack Features |
1 Roller Rack (Upper), 2 Self-Clean Flat Oven Racks (Lower) |
Connected Capabilities |
Amazon Alexa, DiGiorno, Fresco, Google Home, IFTTT, Innit, Sonos, The Google Assistant |
Cabinet Width |
30 in |
Grates |
Included Center Grate |
Air Fry Basket |
Optional- JXAFTRAY1VSS |
Oven Control Features |
Audible Preheat Signal, Auto Oven Shut-Off, Auto Self Clean, Automatic Oven Timer (Time Bake), Chef Connect, Control Lock Capability, Delay Bake Option (Time Bake), Delay Clean Option, Digipad Numeric Entry, Electronic Clock and Timer, Front Controls, In-Oven Broiling, Sabbath Mode, Self-Clean Cool Down Time Display, Temperature Probe |
Electrical Requirements |
208/240V ; 60Hz ; 30A |
Height to Top of Rear Vent Trim |
37.375 in |
Oven Cooking Modes |
Baked Goods - Both Ovens, Convection Bake, Convection Roast, Frozen Pizza Multi Rack - Lower Oven, Frozen Pizza Single Rack - Lower Oven (No Preheat), Frozen Snacks Multi Rack - Lower Oven, Frozen Snacks Single Rack- Lower Oven (No Preheat), No Preheat Air Fry, Proof (Lower Oven), Warming (Both Ovens) |
Trim Kit |
JXFILLR1SS, Optional |
Product Type |
Slide-In Double Oven |
Burner - Left Rear |
5,000 BTU Precise Simmer |
Oven Rack Positions (Single or Upper/Lower) |
6 |
App Filter - Convection |
Yes |
LP Conversion Kit |
Included |
Amp Rating at 240V |
30 |
Ignition System |
Electronic w/Auto Reignition |
Oven Features |
6-Pass Broil Element, 8-Pass Broil Element |
Burner - Center |
9,500 BTU Front / 9,500 BTU Rear |
App Filter - Cooking Technology |
Convection, Traditional |
App Filter - Cabinet Width |
Cooking 30 in. (Standard) |
Configuration |
Double Oven Range |
Burner - Left Front |
21,000 BTU Tri-ring Burner |
App Filter - Product Type |
Ranges Slide-In Double Oven |
Fuel Type |
240V Electric and Natural Gas |
Depth with Door Open |
43.875 in |
Oven Interior |
2 Oven Interior Lights, Black, Hidden Bake |
Approximate Shipping Weight |
291 lb |
Overall Depth |
29.5 in |
Oven Cleaning Type |
Self-Clean with Steam Clean Option |
Cleaning Time |
Variable with Delay Clean Option |
Cooking Technology |
Traditional Upper; Convection Lower |
Height to Cooking Surface (in.) |
36 1/4 +/- 1/4 |
Overall Height |
37.375 in |
Burner - Right Rear |
12,000 BTU |
OU Certified |
No |
App Filter - Fuel Type |
Dual Fuel |
Power Connection |
Power Cord - Not Included |
Amp Rating at 208V |
30 |
Optional Kits |
CXFCGHKPMBT Brushed Black, CXFCGHKPMBZ Brushed Bronze, CXFCGHKPMCG Brushed Brass, CXFCGHKPMCU Brushed Copper, CXFCGHKPMFB Flat Black, CXFCGHKPMSS Brushed Stainless |
Burner - Right Front |
15,000 BTU |
Depth Without Handle |
26.875 in |
Control Type |
Backlit, Glass Touch |
Top Burner BTU Rating - LP (000's BTU's) |
(1) 18.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0; |
Warranty Notes |
See written warranty for full details |
Frameless Oven Door(s) |
Stainless Steel |
Installation |
Flush Appearance, Free-standing cut-out, Power Cord Not Included |
Grill |
Integrated Cast Iron, JXCGRILL1, Optional |
Self-Clean Oven Door Lock |
Automatic |
Top Burner BTU Rating - Nat. Gas (000's BTU's) |
(1) 21.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0 |
Cooking System |
True European Precise Air Reversing |
Cabinet Opening |
30 in |
Cooktop Type |
Standard Grates |
Cooktop Burner Grate Features |
Heavy-Cast Edge-to-Edge Grates |
Control Knobs |
Brushed Bronze Appearance, Weighted |
Net Weight |
271 lb |
Leveling System |
4 Leveling Legs |
Cooktop Burner Grate Material |
Cast-Iron |
Handle Color |
Brushed Bronze |
Broiler Wattage |
3000W Upper / 3600W Lower |
App Filter - Cleaning Type |
Self-Clean |
Handle |
Consumer Removable, Customizable, Professional Style |
Control Location |
Front controls |
Color Appearance |
Matte White |
Dishwasher Safe Knobs |
Yes |
App Filter - Cooktop Type |
Standard Grates |
Cooktop Burner Type |
Sealed |
App Filter - Control Type |
Electronic touchpad |
Overall Width |
29.875 in |
Hertz |
60 |
App Filter - Tri-Ring Burner |
Yes |
Griddle |
Included, Integrated Cast Iron |
Cooktop Surface |
Deep Recessed, Stainless Steel |
Bake Wattage |
2650W Upper / 2650W Lower |
Handle Design |
Café |
Volts/Hertz/Amps |
208/240V; 60Hz; 30A |
Oven Door Features |
Big Clear View Oven Window, Matte White Frameless Oven Door |
Capacity (Cu. Ft.) |
2.7 Upper / 4.3 Lower |
Style |
Commercial |
Labor Warranty |
Limited 1-year entire appliance |
Parts Warranty |
Limited 1-year entire appliance |
Oven Interior Dimensions (W x H x D) (in.) |
24 x 10-1/8 x 19-1/8 - Upper; 24 x 15 x 20-5/8 - Lower |
WiFi Connect |
Built-In |
Sabbath Mode |
Yes |
Valves (Degree of Turn) |
270 |
